Specification

Details

Engine

689cc, liquid-cooled, 4-stroke, DOHC, inline 2-cylinder, 270-degree crankshaft, 8 valves

Power

~73.4 hp (54 kW) @ 8,750 rpm

Torque

~67 Nm (49.4 lb-ft) @ 6,500 rpm

Transmission

6-speed, constant mesh with optional Quick Shift System (QSS)

Brakes

Front: Dual 298mm discs, 4-piston radial-mount calipers, ABS; Rear: 245mm disc, single-piston caliper, ABS

Suspension

Front: 41mm KYB inverted fork, fully adjustable, 120mm travel; Rear: Link-type Monocross shock, adjustable preload and rebound, 130mm travel

Dimensions (LxWxH)

2070 x 705 x 1160 mm

Wheelbase

1395 mm (54.9 in)

Ground Clearance

135 mm (5.3 in)

Fuel Tank Capacity

13 L (3.4 gal)

Mileage

~24 km/L (57 mpg, estimated)

Price (MSRP, USA)

$9,199 + destination charge(Year2025)

Curb Weight

188 kg (414 lb)

Specification

Details

Frame

Steel diamond-type

Drivetrain

Chain drive

Turning Radius

~3.0 m (estimated)

Specification

Details

Front Suspension

41mm KYB inverted fork, fully adjustable, 120mm travel

Rear Suspension

Link-type Monocross shock, adjustable preload and rebound, 130mm travel

Wheels

10-spoke cast aluminum; Front: 17-inch, Rear: 17-inch

Tires

Front: 120/70-ZR17; Rear: 180/55-ZR17

Specification

Details

Seating Capacity

2

Infotainment

None

Instrument Cluster

LCD display with speedometer, tachometer, odometer, trip meter, fuel gauge, gear position, clock

Features

Assist & Slipper clutch, optional Quick Shift System (QSS), aerodynamic R-series bodywork, M-shaped air duct, LED headlights, LED taillight, fully adjustable KYB suspension, dual-channel ABS, 835 mm (32.9 in) seat height, traction control, riding modes, wheelie control

Safety

Dual-channel ABS, traction control, wheelie control

Specification

Details

Colors

Team Yamaha Blue, Matte Raven Black, Intensity White
