Specification

Details

Chassis Platform

Winger 12S

Wheelbase, mm

3488

Engine Make

TATA Motors Limited

Engine Model

VARICOR 11

Engine Type

Compression Ignition Diesel Engine

Engine Capacity

2.2 L DICOR

Engine Power, kW@RPM

73.6 kW (99 HP) @ 4300 r/min

Engine Torque, Nm@RPM

200 Nm @ 1250-3500 r/min

Fuel Type

Diesel

Gearbox

5 Forward + 1 Reverse, Manual

Clutch

215 mm Single Plate Dry Friction Semi Hydraulic Actuation

Steering

Power Assisted Rack and Pinion

Front Brakes

Disc Brakes with Twin Pot Calliper

Rear Brakes

Drum Brakes

Front Suspension

McPherson Strut with Coil Spring

Rear Suspension

Parabolic Leaf Spring, Hydraulic Telescopic Shock Absorber

Axle

Front: Single Reduction, FWD Drive with CV Shaft Arrangement; Rear: Rigid

Battery

12 V; 80 Ah

Alternator

155 A

Side Impact Beams

Yes

Rugged Engine Subframe

Yes

Anti-Roll Bar

Front and Rear

Door Ajar Warning Lamp

Yes (Driver and Co-Driver)

Wheelbase, mm

3488

Length, mm

5458

Width, mm

1905

Height, mm

2670

Internal Height, mm

1900

Ground Clearance, mm

180

Floor Height, mm

495

GVW, kg

3230

Tyre

195 R15 LT, 8PR Radial

Fuel Tank Capacity, L

60

Luggage Space, L

585

Seating Capacity

12+D

Application

Tourist Vans

Feature

Details

Feature: Climate Control

Individual AC Vents

Feature: Seating Comfort

12 Push Back Seats

Feature: Tyres

Bigger Tyre - 15" (195 R15 LT, 8PR Radial)

Feature: Interior Space

Roof Height 1900 mm Internally

Feature: Charging

Multiple USB Charging Points

Feature: Storage

Extra Luggage Space (585 L)

Feature: Engine

2.2 L DICOR Engine

Feature: Suspension

Front: McPherson Strut with Coil Spring; Rear: Parabolic Leaf Spring, Hydraulic Telescopic Shock Absorber

Feature: Clutch

215 mm Single Plate Dry Friction Semi Hydraulic Actuation

Feature: Transaxle

Transaxle

Feature: Brakes

Front: Disc Brakes with Twin Pot Calliper; Rear: Drum Brakes
