Volvo VAH 300 – Diesel Auto Hauler Truck by Volvo Trucks
Specifications
|
Specification |
Details |
|
Truck Model |
VAH 300 |
|
GVW |
49.895 t |
|
Cab Type |
Daycab |
|
Unladen Cab Height |
94.5 in., 97.5 in. |
|
Interior Height |
50 in., 52 in. |
|
Interior Width |
83.5 in. door to door |
|
BBC |
113.6 in. |
|
Drive Axle Configuration |
6x4 tandem |
|
Fuel Type |
Diesel |
|
Application |
Auto Hauler Truck |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Volvo D11, Volvo D13, 4 cycle, Inline Six |
|
Displacement |
10800 cc, 12800 cc |
|
Output |
242.5–317.4 kW (325–425 hp), 302.7–373 kW (405–500 hp) |
|
Torque |
1695–2103 Nm (1250–1550 lb-ft), 1966–2510 Nm (1450–1850 lb-ft) |
|
Emission |
SCR Selective Catalytic Reduction |
|
Transmission |
Volvo I-Shift, 12 forward gears, 4 reverse gears, 15.04:1 gear ratio, 1900 lb-ft max torque |
|
Aspiration |
Sliding Nozzle Variable Geometry Turbocharger |
|
Cam/Valve Configuration |
SOHC, 4 Valves per Cylinder |
|
Cylinder Head |
One Piece Rigid Deck |
|
Injection System |
Common-Rail |
|
Maximum Fuel Injection Pressure |
35000 psi (2400 bar) |
Components & Features
|
Specification |
Details |
|
Air Compressor |
Two Cylinder, 31.8 CFM |
|
Engine Brake |
Volvo Engine Brake (I-VEB), 420 hp or 500 hp @ 2200 rpm, 266 hp or 350 hp @ 1500 rpm |
|
PTO Port |
Optional for Live Rear PTO Pump or Shaft |
|
Preheater |
Electrical, Optional |
|
Oil Capacity |
36 L (10.8 L engine), 40 L (12.8 L engine) |
|
Oil Filtration |
Two Full Flow, One Bypass (10.8 L), Two Full Flow (12.8 L) |
|
Oil Specification |
Volvo VDS-4.5, SAE 10W-30 |
|
FLOCS Oil Drain Kit |
Optional |
|
Trim Level - Fleet |
Heron vinyl headliner and back wall, Wren molded plastic door insert, Hex Grain trim, Two floor insert options |
|
Trim Level - Express |
Heron cloth headliner and back wall, Wren vinyl door insert, Hex Grain trim, Two floor insert options |
|
Trim Level - Premier |
Heron cloth headliner, Longspur cloth back wall with metallic accent, Longspur vinyl door insert, Wood Grain trim, Two floor insert options |
|
Transmission Features |
Fully Integrated Driver Display, Kick Down, Grade Sensor, Load Sensor, Trailer Detection, Remote Diagnostics, Remote Programming OTA, Hill Start Assist, Skip Shift, Idle Drive, Auto Neutral, Intelligent Shifting, Brake Mode, Rock Free and Power Launch, Greatest Possible Downshift, Engine Overspeed Protection, Application Specific Software, Economy and Performance Modes |
