Volvo BZL Electric – Electric City Bus by Volvo Buses
Specifications
|
Specification |
Details |
|
Bus Model |
BZL Electric |
|
GVW |
19.5 t |
|
Overall Dimensions |
9500-13000 mm x 2500 mm (Single Decker), 10900 mm x 2500 mm (Double Decker) |
|
Chassis Length |
8515 mm (Single Decker), 10585 mm (Double Decker) |
|
Fuel Type |
Electric |
|
Battery Capacity |
Up to 470 kWh |
|
Application |
Electric City Bus |
Frame & Drivetrain
|
Specification |
Details |
|
Motor Type |
Permanent Magnet Synchronous Motor |
|
Electric Motor Output |
200 kW or 400 kW (Single Decker), 200 kW (Double Decker) |
|
Max Wheel Torque |
19000 Nm or 31000 Nm (Single Decker), 19000 Nm (Double Decker) |
|
Gearbox |
2-speed automated manual transmission |
|
Charging System |
OppCharge: 300 kW (roof charging); CCS: 150 kW |
|
Emission |
Zero Emission |
Suspension & Brakes
|
Specification |
Details |
|
Front Axle |
Volvo RFS-L |
|
Rear Axle |
ZF AV133 |
|
Power Steering |
Electrically driven hydraulic steering |
|
Brake Systems |
Volvo disc brakes, Electronic Braking System (EBS5), Anti-lock Braking System (ABS), Acceleration Slip Regulator (ASR), Brake blending, Hill Start Aid, Electronic Stability Control |
Components & Features
|
Specification |
Details |
|
Driver’s Environment - Dashboard |
Volvo dashboard or limited dashboard, supplemented by bodybuilder |
|
Driver’s Environment - Dashboard Movement |
Dashboard moves with steering column for height and tilt (Volvo dashboard) |
|
Driver’s Environment - Instrument Cluster |
Instrument cluster |
|
Driver’s Environment - Tachograph |
Tachograph |
|
Driver’s Environment - Data Logging |
Data logging |
|
Driver’s Environment - Alcolock |
Volvo Alcolock |
|
Driver’s Environment - Temperature Gauge |
Outdoor temperature gauge |
|
Air Conditioning System |
Chassis prepared for roof-mounted HVAC units, high-voltage heaters preassembled (0–24 kW) |
|
Energy Storage System |
Chassis with energy storage system module for roof mounting |
