Volvo B5L S-Charge Hybrid City Bus
Specifications
|
Specification |
Details |
|
Model |
B5L S-Charge |
|
Overall Chassis Length |
Up to 12,500 mm (depending on body) |
|
Frame Height at Rear Structure |
2,268 mm |
|
Overall Width Front Wheels |
2,500 mm |
|
Overall Width Rear Wheels |
2,500 mm |
|
Front Overhang |
2,498 mm |
|
Rear Overhang |
3,430 mm |
|
Permitted GVW |
19,500 kg |
|
Fuel Type |
Hybrid (Diesel/Electric) |
|
Application |
City Bus |
Frame & Drivetrain
|
Specification |
Details |
|
Wheelbase |
3,250 mm |
|
Track, Front |
2,107 mm |
|
Track, Rear |
1,885 mm |
|
Engine |
Volvo D5K240, 4-cylinder, in-line, 5.1 dm³ |
|
Electric Motor |
Volvo I-SAM, 110 kW/800 Nm (max), 30 kW/400 Nm (continuous) |
|
Transmission |
Volvo I-Shift AT2412F |
|
Front Axle |
Volvo RFS-L |
|
Rear Axle |
ZF AV 133 |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Air bellows (2 front, 4 rear), optional kneeling |
|
Brakes |
Volvo disc brakes, Electronic Braking System (EBS 5), Electronic Stability Control (ESC), Anti-lock Braking System (ABS), Acceleration Slip Regulation (ASR), Brake Blending, Dual Retarder Control, Drag Torque Control, Hill Start Aid, Brake Temperature Warning, Poor Brake Performance Warning, Door Brake, Brake Assistant, Lining Wear Sensing and Analysis, Automatic Calibration after Brake Pad Change |
|
Steering |
Electric driven hydraulic steering, max wheel angle 53°, RHD/LHD |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
275/70 R22.5 |
|
Rims |
Steel, 7.5 x 22.5" |
Components & Features
|
Feature |
Details |
|
Emission Standard |
Euro 6, certified for biodiesel (EN 14214) and HVO (EN 15940) |
|
Engine Output |
240 hp (180 kW ISO 1585) |
|
Engine Torque |
918 Nm at 1,200–1,600 rpm (ISO 1585) |
|
Electric Motor Brake Torque |
550 Nm (max), 400 Nm (continuous) |
|
Fuel Tanks |
Diesel: 220 L (RHD) / 250 L (LHD), AdBlue: 30 L (RHS) |
|
Energy Storage System |
Lithium-ion battery, water cooled, 600 V, 9 kWh (BOL) |
|
Exhaust System |
One box muffler design, Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR), Ammonia Slip Catalyst (ASC), automatic and parked regeneration |
|
Cooling System |
Roof-mounted radiator, charge air cooler, electrically driven fans with speed control, remote coolant filling, no coolant filter, coolant level warning, higher allowed coolant temperature, ESS Active Cooler (hot markets), ESS Passive Cooler (standard) |
|
Instrument Cluster |
Speedometer, rev counter, 6.5" display, fuel gauge, coolant temperature, brakes, turbo and oil pressure, indicators, warning lamps |
|
Driver’s Station |
Tachograph, data logging, Volvo Alcolock (option), external temperature meter, fuel economy meter, I-Coaching, engine controls in engine compartment |
|
Electrical System |
I-Start dual battery system (2x12 V start batteries at 2x35 Ah, 2x12 V consumer batteries at 2x170 Ah or 2x225 Ah), automatic shut off at low voltage, electric air compressor |
|
Air System |
Compressed air system, easily filled from external circuit |
