Specification

Details

Model

9700 DD 4.0m 6x2

Overall Length

13,000–14,800 mm

Overall Width

2,550 mm

Overall Height

4,000 mm (with or without AC)

Permitted GVW

26,500 kg

Passenger Capacity

Up to 100 (depending on seat layout and comfort level)

Luggage Capacity

Up to 8.0 m³ (compartment), up to 3.0 m³ (interior racks)

Fuel Type

Diesel

Application

Double Decker Coach

Specification

Details

Wheelbase

5,360–7,160 mm

Bogie

1,400 mm

Front Overhang

2,810 mm

Rear Overhang

3,430 mm

Turning Radius (Outer Front Corner)

10,040 mm, 11,890 mm, 12,490 mm

Turning Radius (Outer Front Wheel)

8,070 mm, 9,920 mm, 10,520 mm

Engine

Volvo D13K, 6-cylinder, in-line, 13 dm³, SCR, common rail

Transmission

Volvo I-Shift AT2612G

Specification

Details

Suspension

Kneeling, full side or right front corner

Brakes

Volvo disc brakes, Electronic Stability Control (ESC), Electronic Braking System (EBS 5), Anti-lock Braking System (ABS), Acceleration Slip Regulation (ASR), Brake Blending, Collision Warning with Emergency Brake (CW-EB)

Steering

Hydraulic power steering, LHD

Specification

Details

Tyres

315/70 R22.5

Rims

Steel, aluminium, Dura-Bright®, 9.00 x 22.5

Feature

Details

Emission Standard

Euro 6, compatible with HVO (EN 15940) and biodiesel (B100)

Engine Output

460 hp (±0–4%, 340 kW) or 500 hp (±0–4%, 370 kW) ISO 1585

Engine Torque

2,500 Nm at 1,000–1,400 rpm (ISO 1585)

Fuel Tanks

Diesel: 2x205 L, 3x205 L, 4x205 L, or 4x205 L + 155 L; AdBlue: 64 L or 90 L (LHS)

Exhaust System

One box muffler design, Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR), Ammonia Slip Catalyst (ASC), automatic DPF regeneration, OBD for emissions (step D)

Cooling System

Split configuration with electrical fans, no coolant filter, higher allowed coolant temperature

Exterior and Structure

Carrus Delta OY bodywork, stainless steel structure and side panelling, composite front/rear walls, anti-corrosion treatment, electrical heating and UV-protection in windscreen, tinted double-glazed side/rear windows, electrically operated heated driver window, central locking luggage compartment, brackets for ski-box/cycle carrier, Bi-Xenon headlights with LED DRL

Doors and Door System

First, second, third doors outward swinging, double-glazed; wheelchair ramp (fixed manual or removable) in middle door

Convectors

Heating capacity: 470 W/m (Q60), 780 W/m (Q100)

Defroster

Heating capacity: 16 kW (Q80), cooling capacity: 5 kW max, airflow: 730 m³/h max at dP 0, available with/without AC

Auxiliary Heater

Heating capacity: 30 kW

Interior

Multiple material/colour options, curtains or sun blinds, 100-litre water toilet, multiple storage box sizes/locations, safe box, passenger display with clock and exterior temperature, LED reading lights, safety illumination for staircases, special emergency interior illumination, fire detection system

Passenger Seats

Volvo coach line or intercity line, customizable specifications

Driver’s Station

Steering wheel (450 mm or 500 mm), tachograph, Volvo Alcolock, Knee Impact Protection (KIP), external temperature meter, ISRI driver’s seat, Lane Keeping Support (LKS), Adaptive Cruise Control, Driver Alert System (DAS), 360° view camera, rear view camera with washer, camera system for mirror replacement

Electrical System

Volvo I-Start system, automatic shut off at low voltage, automatic circuit breakers, starter batteries (2x35 Ah), consumer batteries (2x210 Ah), alternators max output 4x150 A

Audiovisual System

Bosch audio/video system, two DIN units with radio and DVD, driver’s monitor, driver and guide microphones, USB, subwoofer, DAB+, HDMI
