Specification

Details

Tractor Model

S286

Vehicle Category

Tractor

Fuel Type

Diesel

Application

Crop Farming, Contracting, Forestry

Specification

Details

Engine

AGCO Power 84 LXTN-D5, 6 cylinders, 8.4 L

Max Power (Standard)

280 HP / 206 kW @ 1850 RPM

Max Power (Boost)

310 HP / 228 kW @ 1850 RPM

Max Torque (Standard)

1250 Nm @ 1500 RPM

Max Torque (Boost)

1400 Nm @ 1500 RPM

Engine Nominal Speed

1950 RPM

Idle Speed

850 RPM; 750 RPM (Shuttle Lever on P)

Oil-Change Interval

500 hours

Transmission Type

AGCO ML 260 CVT

Number of Work Areas

2 (A: 0–28 km/h; B: 0–53 km/h)

Speed Range

Forward: 0–53 km/h @ 1500 RPM; Reverse: 0–38 km/h

Specification

Details

Front Axle Suspension

Hydraulic (Option)

Specification

Details

Front Tyres

600/70R30 inches (Standard); VF650/60R34F inches (Option 1)

Rear Tyres

710/70R42 inches (Standard); VF900/60R42F inches (Option 1)

Specification

Details

Exhaust Cleaning System

DOC + DPF + SCR

Rear PTO

540E @ 1577 RPM; 1000 @ 1882 RPM; 1000E @ 1605 RPM

Front PTO

1000 @ 1900 RPM (Option)

Hydraulics Type

Closed Center Load Sensing

Pump Capacity

ECO: 205 l/min @ 1650 RPM; 200 + 200: 400 l/min @ 1950 RPM

Exportable Hydraulic Oil

77 Litres

Rear Service Valves

ECO: 4, 5, or 6 (with decompression); 200 + 200: 6 (with decompression)

Front Service Valves

2 or 3

Lifting Power (Rear)

12000 kg

Lifting Power (Front)

5800 kg

Fuel Capacity

610 Litres

AdBlue Capacity

70 Litres

Wheelbase

3092 mm

Length

5730 mm (Front Linkage, Transport); 6235 mm (Front Linkage, Lowered)

Height

3489 mm (with Valtra Guide); 3637 mm (with Beacon); 3409 mm (without Guide/Telemetry); 3359 mm (SRI 1025 Tyres)

Width

2550–2900 mm (Tractor); 2550 mm or 2750 mm (Mudguard)

Ground Clearance

528 mm (Mid); 541 mm (Rear, No Hitch)

Weight

12000 kg (Own, Full Tanks + Driver); Max 16000 kg (50 km/h); Max 18000 kg (40 km/h)

Weight Distribution

47% Front / 53% Rear

Turning Radius

8.0 m
