Specification

Details

Tractor Model

G125

Vehicle Category

Tractor

Fuel Type

Diesel

Application

Agricultural Tractor

Specification

Details

Engine Power

ECO: 86 kW / 115 HP (Max), 93 kW / 125 HP (Max Boost); STD: 93 kW / 125 HP (Max), 97 kW / 130 HP (Max Boost)

Engine Type

AGCO Power 44 MBTN-D5 (4-cylinder)

Engine Capacity

4.4 Litres

Engine Speed at Max Power

ECO: 1750 RPM; STD: 2000 RPM

Engine Nominal Speed

2200 RPM

Max Torque

ECO: 518 Nm (Standard), 555 Nm (Boost) at 1250 RPM; STD: 520 Nm (Standard), 540 Nm (Boost) at 1500 RPM

Transmission Type

Powershift, 24+24R (6 speeds per work area, 4 work areas: A, B, C, D); 48+48R with Creeper (Option)

Speed Range

1.65–43 km/h at 2200 RPM; 43 km/h at 1910 RPM (Standard) or 1640 RPM (EcoSpeed); Creeper: 0.11 km/h at 2200 RPM (Option)

Specification

Details

Front Tyres (Standard)

340/85R24 inches

Standard Tyres Rear

420/85R34 inches

Specification

Details

Drive

4WD

Rear PTO

540 at 1920 RPM, 1000 at 1964 RPM; Optional: 540E at 1560 RPM, Ground Speed (Ratio 29.23)

Hydraulics Type

HiTech: Open Centre; Active/Versu: Load Sensing

Hydraulic Pump

HiTech: 100 l/min; Active/Versu: 110 l/min

Max Valves (Rear)

HiTech: 2 or 3 (Mechanical); Active: 3 or 4 (Electrical); Versu: 4 (Electrical); Optional ON/OFF Valve: 1

Max Valves (Front)

2, 3, or 4 (Electrical)

Max Available Hydraulic Oil Volume

24 Litres (44 Litres with Extra Filling)

Max Lift Capacity (Rear)

60 kN (Max); 50 kN (Entire Lift Range)

Max Lift Capacity (Front)

30 kN (Optional)

Overall Width

Max 2380 mm

Overall Length

4452 mm (Without Front Linkage); 4514 mm (With Front Linkage)

Total Height

2755–2830 mm (Without Valtra Guide); 2910 mm (With Valtra Guide)

Ground Clearance

Mid: 443 mm; Rear (No Hitch): 460 mm

Wheelbase

2550 mm

Turning Radius

4.36 m

Total Weight

5140 kg (Full Tanks, With Driver); 9500 kg (Max)

Fuel Tank Capacity

200 Litres (Basic); 160 Litres (Steel Tank); 21 Litres (AdBlue)
