Valtra F75 – Agricultural Tractor by Valtra
Specifications
|
Specification |
Details |
|
Tractor Model |
F75 |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor (Specialized for Vineyards and Orchards) |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Power |
55 kW / 75 HP (Max) |
|
Engine Type |
FPT F28 EU Stage V (4-cylinder, Common Rail) |
|
Engine Capacity |
2.8 Litres |
|
Max Torque |
350 Nm |
|
Transmission Type |
Mechanical Shuttle: 12+12R or 24+24R (with Splitter); Power Shuttle: 24+12R |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres (Standard) |
16 inches |
|
Standard Tyres Rear |
24 inches |
Components & Features
|
Specification |
Details |
|
Drive |
4WD |
|
Rear PTO |
540/1000 or 540/540E; Ground Speed PTO (Option) |
|
Hydraulics Type |
Open Centre |
|
Hydraulic Pump |
2 Pumps: 60 + 27 l/min; 3 Pumps: 60 + 27 + 27 l/min |
|
Max Valves (Rear) |
2 or 3 (2 Pumps); 2, 3, or 4 (3 Pumps) |
|
Max Lift Capacity (Rear) |
2.6 or 3 tons |
|
Max Lift Capacity (Front) |
1.8 tons (Optional) |
|
Overall Width |
Standard: 1544–1944 mm; Narrow: 1278–1785 mm |
|
Overall Length |
3980 mm |
|
Total Height |
Cab: 2478 mm (Rear Wheels 380/70R28); ROPS (Folded): 1400 mm |
|
Wheelbase |
Standard: 2154 mm; Narrow: 2178 mm |
|
Turning Radius |
3.6 m |
|
Total Weight |
Standard Open (ROPS): Max 3120 kg; Standard Cab: Max 3485 kg; Narrow Cab: Max 3375 kg |
