ULTRA Prime 50 plus D LPO11 6 54 – Tata Motors Bus
Specifications
|
Parameter |
Details |
|
Bus Model |
LPO 11.6/54 |
|
Wheelbase |
5400 mm |
|
Engine |
3.3 LTR |
|
Engine Power |
117 kW @ 2600 RPM |
|
Engine Torque |
475 Nm @ 1600-2000 rpm |
|
Clutch Diameter |
330 mm |
|
Gearbox |
G 550 6 Speed Cable Shift |
|
Brakes |
Air Brakes |
|
Suspension |
Dual Stage Parabolic Suspension |
|
Steering |
Power-Steering, Tilt - Telescope |
|
Battery |
12 V / 24 V, 120 Ah |
|
Alternator |
120 A / 150 A |
|
Tyres |
235/75 R17.5 |
|
Fuel Tank Capacity |
160 litres (Plastic) |
|
DEF Tank Capacity |
18/25 litres |
|
Max. GVW |
10800 kg |
|
Seating Capacity |
SKL: 58, STD: 40 / 44 / 50 & 55; 40-68 |
|
Length |
10440 mm |
|
Rear Overhang |
3240 mm |
|
Front Overhang |
1800 mm |
|
Overall Height |
2910/3120 mm |
|
Max. Width |
2340/2550 mm |
|
TCD |
19.5 m |
|
Ground Clearance |
180 mm |
|
AC / Non-AC Option |
Both |
|
Fuel Type |
Diesel |
|
Application |
Staff & Contract Buses |
Components & Features
|
Component/Feature |
Details |
|
Feature: Warranty |
4 Years/4 Lakh kms |
|
Feature: Bus Body Warranty |
3 Years/3 Lakh kms |
|
Feature: Multiple Body Width Options |
2200 MM / 2340 MM & 2550 MM |
|
Feature: Engine Efficiency |
Fuel efficient 3.8 SGI Engine with Balanced power & Torque |
|
Feature: Cooling System |
E Viscous Fan |
|
Feature: Tyre Type |
Low CRR Radial Tubeless & Tubetype Tyre |
|
Feature: Telematics |
4G Telematic Solution with FOTA |
|
Feature: Steering Wheel |
Modular steering wheel with Cruise Control |
|
Feature: Fuel Filling System |
Integrated fuel filling system for Fast & Slow filling |
|
Feature: Safety System |
Fire detection and alarm system |
|
Feature: Fuel Economy Switch |
Multi Mode Fuel Economy Switch |
|
Feature: Stability Control |
Electronic Stability Control with Hill Start Assist |
|
Feature: Driver Comfort |
Driver suspended Seats |
|
Feature: Gear Shift Advisor |
Torque Based Gear Shift Advisor |
|
Feature: Wheel Bearing |
Unitised Wheel Bearing |
|
Feature: Seating Comfort |
Wider seats, armrests, mobile chargers, added leg space, reclining seats |
|
Feature: Suspension |
Improved suspension |
|
Feature: Noise Reduction |
Reduced Noise, Vibration & Harshness (NVH) |
|
Feature: Safety Standards |
Safety standards exceeding CMVR, AIS 052, AIS 063, AIS 153 |
|
Feature: Braking System |
Advanced braking systems |
|
Feature: Materials |
Impact-resistant materials |
|
Feature: Emergency Exits |
Strategic emergency exits |
|
Feature: Bus Body Design |
Superior bus body design in collaboration with ACGL, prioritizing structural integrity and aesthetics |
|
Feature: Service Interval |
Service interval of 40,000 km |
|
Benefit: Safety |
Sturdy build quality for passenger & driver safety |
|
Benefit: Performance |
More reliable, better performance, more profits to customers |
|
Benefit: Seating Comfort |
Increased number of seats and seat width for seating comfort |
|
Benefit: Fuel Economy |
More trips with highest fuel economy |
|
Benefit: Aesthetics |
Refreshed look, end customer preference |
|
Benefit: Passenger Comfort |
Increased comfort and convenience to passengers |
|
Benefit: Resale Value |
Better resale value |
|
Benefit: Noise Reduction |
Low noise, vibration & harshness |
|
Benefit: Maintenance |
Low maintenance with value-added service options |
|
Benefit: Customer Support |
24x7 customer care and roadside assistance |
|
Benefit: Spare Parts |
Spare part availability across the country |
