2025 Trek Service Electric – Electric Service Bike
Specifications
|
Specification |
Details |
|
Model |
Service Electric |
|
Vehicle Category |
Electric Service Bike |
|
Application |
Utility, service, commuting |
|
Starting Price (2025) |
$4,999.99 USD |
|
Color Options |
Trek Black |
|
Sizes |
S, M, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Alpha Platinum Aluminum, internal cable routing, rack and fender mounts, 141x5mm QR |
|
Fork |
SR Suntour NVX30, coil spring, 100mm travel, 100x5mm QR |
|
Drivetrain Compatibility |
Shimano CUES, 1x10-speed, mechanical |
|
Dropouts |
100x5mm QR (F), 141x5mm QR (R) |
|
Crank |
Shimano CUES U6000, 36T, 170mm (S, M), 175mm (L, XL) |
|
Chain |
Shimano CUES LG500, 10/11-speed |
|
Rear Derailleur |
Shimano CUES U6000, 10-speed, mechanical |
|
Shifters |
Shimano CUES U6000, 10-speed, mechanical |
|
Cassette |
Shimano CUES LG400, 11-46T, 10-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Commuter, 165mm width |
|
Fuel Type |
Electric (Bosch Performance Line CX motor) |
|
Cargo Capacity |
Rear rack (25kg capacity), front rack mounts, fender mounts, downtube water bottle mounts |
|
Wheels/Tyres |
Bontrager H2 Comp, 27.5x2.40", puncture-resistant |
|
Wheel Size |
27.5" in |
|
Brakes |
Shimano MT200, hydraulic disc, 180mm rotor (F, R) |
|
Brake Levers |
Shimano MT201, hydraulic |
|
Handlebar |
Bontrager alloy, 31.8mm, 15mm rise, 720mm width |
|
Stem |
Bontrager alloy, 31.8mm, 7 degree, 60mm length (S, M), 70mm length (L, XL) |
|
Headset |
Semi-integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
|
Saddle |
Bontrager Commuter, 165mm width |
|
Seatpost |
Bontrager alloy, 31.6mm, 12mm offset, 330mm length (S, M), 400mm length (L, XL) |
|
Seatpost Clamp |
Integrated, internal |
|
Grips |
Bontrager Satellite, ergonomic |
|
Front Hub |
Bontrager alloy, sealed bearing, 100x5mm QR |
|
Rear Hub |
Bontrager alloy, sealed bearing, Shimano 10/11-speed freehub, 141x5mm QR |
|
Rims |
Bontrager H2 Comp, 27.5", 32-hole |
|
Spokes |
14g stainless steel |
|
Pedals |
Wellgo VPE-537, platform, plastic |
|
Exterior Features |
Rear rack (25kg capacity), front rack mounts, fender mounts, downtube water bottle mounts, kickstand mount, integrated lights |
|
Motor |
Bosch Performance Line CX, 85Nm, 250W continuous power, 28mph/45kph max assist (Class 3) |
|
Battery |
Bosch PowerTube 625Wh, integrated, removable |
|
Controller |
Bosch LED remote, 4 assist modes (Eco, Tour, eMTB, Turbo), walk assist |
|
Charger |
Bosch 4A charger |
