2025 Trek Madone SLR 9 Gen 8 – Road Bike
Specifications
|
Specification |
Details |
|
Model |
Madone SLR 9 Gen 8 |
|
Vehicle Category |
Road Bike |
|
Application |
Road racing, climbing, sprinting |
|
Starting Price (2025) |
$12,899.99 USD |
|
Color Options |
Purple Phaze/Amethyst Marble, Matte Carbon Smoke/Prismatic Pearl, Deep Smoke, Viper Red, Team Trek-Segafredo Replica |
|
Sizes |
XS, S, M, ML, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
900 Series OCLV Carbon, IsoFlow technology, internal cable routing, flat mount disc, 142x12mm thru axle |
|
Fork |
Madone OCLV Carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
|
Drivetrain Compatibility |
Shimano Dura-Ace Di2, 2x12-speed |
|
Dropouts |
142x12mm thru axle (R), 12x100mm thru axle (F) |
|
Crank |
Shimano Dura-Ace R9200, 52/36, 165mm (XS), 170mm (S, M), 172.5mm (ML, L), 175mm (XL) |
|
Chain |
Shimano Dura-Ace/XT M8100, 12-speed |
|
Rear Derailleur |
Shimano Dura-Ace Di2 R9250, 12-speed |
|
Front Derailleur |
Shimano Dura-Ace Di2 R9250, braze-on |
|
Shifters |
Shimano Dura-Ace Di2 R9270, 12-speed |
|
Cassette |
Shimano Dura-Ace R9200, 11-30, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Aeolus Elite, carbon rails, 145mm width |
|
Wheels/Tyres |
Bontrager Aeolus RSL 51, OCLV Carbon, tubeless ready, 51mm depth, 700x25c |
|
Wheel Size |
700c |
|
Brakes |
Shimano Dura-Ace hydraulic disc, flat mount, 160mm rotors |
|
Brake Levers |
Integrated with shifters |
|
Handlebar |
Bontrager Aeolus RSL Integrated Bar/Stem, OCLV Carbon, 38cm (XS), 40cm (S), 42cm (M, ML), 44cm (L, XL) |
|
Stem |
Integrated with handlebar, 80mm (XS, S), 90mm (M), 100mm (ML, L), 110mm (XL) |
|
Headset |
Integrated, cartridge bearing, sealed |
|
Saddle |
Bontrager Aeolus Elite, carbon rails, 145mm width |
|
Seatpost |
Madone aero carbon seatmast cap, 0mm offset, 175mm (XS, S), 200mm (M, ML, L, XL) |
|
Seatpost Clamp |
Integrated with seatmast |
|
Grips |
Bontrager Supertack Perf tape |
|
Front Hub |
Bontrager Aeolus RSL, carbon, 100x12mm thru axle |
|
Rear Hub |
Bontrager Aeolus RSL, carbon, Shimano 11/12-speed freehub, 142x12mm thru axle |
|
Rims |
Bontrager Aeolus RSL 51, OCLV Carbon, tubeless ready, 51mm depth, Presta valve |
|
Spokes |
14/17g stainless steel, black |
|
Exterior Features |
IsoFlow technology, tubeless ready wheels, internal cable routing |
|
Weight |
7.05 kg / 15.55 lbs (size ML, with TLR sealant, no tubes, no bottles/cages) |
