2025 Trek Madone SL 7 AXS Gen 8 – Performance Road Bike
Specifications
|
Specification |
Details |
|
Model |
Madone SL 7 AXS Gen 8 |
|
Vehicle Category |
Performance Road Bike |
|
Application |
Road racing, climbing, sprinting |
|
Starting Price (2025) |
$9,499.99 USD |
|
Color Options |
Team Replica, Black-Grey, Blue, Purple, White-Tan |
|
Sizes |
XS, S, M, ML, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
900 Series OCLV Carbon, IsoFlow technology, road race geometry, internal cable routing, 32mm max tire clearance |
|
Fork |
Madone Gen 8 Carbon, tapered carbon steerer, internal brake routing, 12x100mm thru axle |
|
Drivetrain Compatibility |
SRAM Force AXS E1, 2x12-speed, wireless |
|
Dropouts |
12x100mm thru axle (F), 12x142mm thru axle (R) |
|
Crank |
SRAM Force AXS E1, 50/37T, power meter, 165mm (XS, S), 170mm (M, ML), 172.5mm (L), 175mm (XL) |
|
Chain |
SRAM Force, 12-speed |
|
Rear Derailleur |
SRAM Force AXS E1, 12-speed, wireless |
|
Front Derailleur |
SRAM Force AXS E1, 12-speed, wireless |
|
Shifters |
SRAM Force AXS E1, 12-speed, wireless |
|
Cassette |
SRAM Force XG-1270, 10-33T, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Aeolus Pro, carbon rails, 145mm width |
|
Cargo Capacity |
RSL Aero Bottles and Cages (included) |
|
Wheels/Tyres |
Bontrager Aeolus Pro 51, OCLV Carbon, tubeless ready, 25mm width, Bontrager R3 Hard-Case Lite, 700x32mm |
|
Wheel Size |
700c |
|
Brakes |
SRAM Force AXS E1, hydraulic disc, flat mount, 160mm rotor (F, R) |
|
Brake Levers |
SRAM Force AXS E1, hydraulic |
|
Handlebar |
Trek Aero RSL, OCLV Carbon, 80mm reach, 124mm drop, 37cm (XS), 39cm (S), 41cm (M, ML), 43cm (L), 45cm (XL) |
|
Stem |
Integrated with Trek Aero RSL bar/stem, 80mm (XS, S), 90mm (M), 100mm (ML, L), 110mm (XL) |
|
Headset |
Integrated, sealed cartridge bearing, 1-1/8" top, 1-3/8" bottom |
|
Saddle |
Bontrager Aeolus Pro, carbon rails, 145mm width |
|
Seatpost |
Madone aero carbon seatmast cap, 0mm offset, 135mm (XS, S), 165mm (M, ML, L, XL) |
|
Seatpost Clamp |
Integrated, internal |
|
Grips |
Bontrager Supertack Perf tape |
|
Front Hub |
Bontrager alloy, sealed bearing, 12x100mm thru axle |
|
Rear Hub |
Bontrager alloy, sealed bearing, 12x142mm thru axle, SRAM XDR freehub |
|
Rims |
Bontrager Aeolus Pro 51, OCLV Carbon, tubeless ready, 25mm width |
|
Spokes |
14/17g stainless steel |
|
Exterior Features |
IsoFlow technology, internal cable routing, RSL Aero Bottles and Cages, road race geometry |
|
Weight |
7.22 kg / 15.92 lbs (ML, with TLR sealant, no tubes, no bottles/cages) |
