2025 Trek Madone SL 6 XS Gen 8 – Road Bike
Specifications
|
Specification |
Details |
|
Model |
Madone SL 6 XS Gen 8 |
|
Vehicle Category |
Road Bike |
|
Application |
Road racing, endurance road cycling |
|
Starting Price (2025) |
$4,599.97 USD (Original: $6,499.99) |
|
Color Options |
Matte Dark Web, Gloss Crystal White/Matte Deep Smoke, Gloss Fury Red/Matte Deep Smoke |
|
Sizes |
XS, S, M, ML, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
500 Series OCLV Carbon, IsoFlow technology, internal routing, BSA 68, 32mm max tire size |
|
Fork |
Madone SL carbon, tapered steerer, internal brake routing, 12x100mm thru axle |
|
Drivetrain Compatibility |
SRAM Rival XS E1, 2x12 |
|
Dropouts |
12x100mm thru axle (F), 12x142mm thru axle (R) |
|
Crank |
SRAM Rival XS, 48/35T, 165mm (XS, S), 170mm (M), 172.5mm (ML, L), 175mm (XL) |
|
Chain |
SRAM Rival, 12-speed |
|
Rear Derailleur |
SRAM Rival XS E1 |
|
Front Derailleur |
SRAM Rival XS E1 |
|
Shifters |
SRAM Rival XS E1, 12-speed |
|
Cassette |
SRAM XG-1250, 10-36, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Aeolus Comp, steel rails, 145mm width |
|
Wheels/Tyres |
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50mm rim depth, 32mm max tire size |
|
Wheel Size |
700c |
|
Brakes |
SRAM Rival hydraulic disc, 160mm rotors |
|
Brake Levers |
SRAM Rival XS E1 |
|
Handlebar |
Bontrager Elite Aero VR-CF, alloy, 31.8mm, 380mm (XS), 400mm (S, M), 420mm (ML, L), 440mm (XL) |
|
Stem |
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm (XS), 80mm (S), 90mm (M, ML), 100mm (L), 110mm (XL) |
|
Headset |
Integrated, sealed cartridge bearing |
|
Saddle |
Bontrager Aeolus Comp, steel rails, 145mm width |
|
Seatpost |
Madone aero carbon seatmast cap, 5mm offset, 175mm (XS, S, M), 200mm (ML, L, XL) |
|
Seatpost Clamp |
Integrated with seatmast |
|
Grips |
Bontrager Supertack Perf tape |
|
Front Hub |
Bontrager alloy, sealed bearing, 12x100mm thru axle |
|
Rear Hub |
Bontrager alloy, sealed bearing, SRAM XDR freehub, 12x142mm thru axle |
|
Rims |
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50mm rim depth |
|
Spokes |
14g stainless steel, black |
|
Exterior Features |
IsoFlow technology, internal routing, aero frame design, two-piece cockpit |
|
Weight |
8.43 kg / 18.59 lbs (size ML, with TLR sealant, no tubes) |
