Specification

Details

Model

Madone SL 5 Gen 8

Vehicle Category

Road Bike

Application

Road racing, climbing, sprinting

Starting Price (2025)

$3,299.97 USD (Sale from $3,699.99)

Color Options

Matte Deep Smoke, Galactic Blue

Sizes

XS, S, M, ML, L, XL

Specification

Details

Frame

500 Series OCLV Carbon, IsoFlow technology, internal cable routing, 142x12mm thru axle

Fork

Madone KVF full carbon, 100x12mm thru axle

Drivetrain Compatibility

Shimano 105, 2x12

Dropouts

100x12mm thru axle (F), 142x12mm thru axle (R)

Crank

Shimano 105 R7000, 50/34, 165mm (XS), 170mm (S, M), 172.5mm (ML, L), 175mm (XL)

Chain

Shimano SLX M7100, 12-speed

Rear Derailleur

Shimano 105 R7000, 34T max cog

Front Derailleur

Shimano 105 R7000, braze-on

Shifters

Shimano 105 R7000, 12-speed

Cassette

Shimano 105 CS-HG700, 11-34, 12-speed

Specification

Details

Seating

Bontrager Aeolus Comp, steel rails, 145mm width

Wheels/Tyres

Bontrager Aeolus Elite 50, OCLV Carbon, tubeless ready, 700x25mm

Wheel Size

700c

Brakes

Shimano 105 R7070 hydraulic disc, 160mm rotors

Brake Levers

Shimano 105 R7020 hydraulic

Handlebar

Bontrager Comp VR-C, alloy, 31.8mm, 38cm (XS), 40cm (S, M), 42cm (ML, L), 44cm (XL)

Stem

Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm (XS), 80mm (S), 90mm (M, ML), 100mm (L), 110mm (XL)

Headset

FSA IS-2, 1-1/8in top, 1.5in bottom, sealed cartridge bearing

Saddle

Bontrager Aeolus Comp, steel rails, 145mm width

Seatpost

Bontrager alloy, 27.2mm, 20mm offset, 330mm length

Grips

Bontrager Supertack Perf tape

Front Hub

Bontrager alloy, sealed bearing, 6-bolt, 100x12mm thru axle

Rear Hub

Bontrager alloy, sealed bearing, 6-bolt, Shimano 11/12-speed freehub, 142x12mm thru axle

Rims

Bontrager Aeolus Elite 50, OCLV Carbon, tubeless ready, 50mm depth

Spokes

14g stainless steel, black

Exterior Features

IsoFlow technology, internal cable routing, two-piece cockpit, road race geometry

Weight

8.70 kg / 19.19 lbs (size ML, with tubes)
