Specification

Details

Model

FX Sport SL 5

Vehicle Category

Fitness Bike

Application

Fitness, all-road, commuting

Starting Price (2025)

$2,299.99 USD

Color Options

Gloss Alpine Blue/Matte Deep Smoke, Deep Dark Green/Black

Sizes

S, M, L, XL

Specification

Details

Frame

400 Series OCLV Carbon, internal cable routing, 3S chain keeper, DuoTrap S compatible, fender mounts, flat mount disc, 135x5mm QR

Fork

FX Carbon, tapered carbon steerer, flat mount disc, rack mounts, 405mm axle-to-crown, ThruSkew 5mm QR

Drivetrain Compatibility

SRAM Apex, 1x12-speed

Dropouts

135x5mm QR (F), 135x5mm QR (R)

Crank

SRAM Apex 1, 40T, DUB Wide, 170mm length (S, M), 175mm length (L, XL)

Chain

SRAM Apex, 12-speed

Rear Derailleur

SRAM Apex Eagle, 12-speed

Shifters

SRAM Apex, 12-speed

Cassette

SRAM PG-1230 Eagle NX, 11-50T, 12-speed

Specification

Details

Seating

Bontrager H1, 145mm width

Cargo Capacity

Fender mounts, rack mounts

Wheels/Tyres

Bontrager GR2 Hard-Case Lite, tubeless ready, 700x40mm

Wheel Size

700c

Brakes

Shimano MT201 hydraulic disc, UR300 flat-mount caliper, 160mm rotor

Brake Levers

Shimano MT201 hydraulic

Handlebar

Bontrager Satellite Plus IsoZone, alloy, 31.8mm, 15mm rise, 600mm width (S), 620mm width (M, L, XL)

Stem

Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 90mm length (S, M), 100mm length (L, XL)

Headset

1-1/8" integrated, sealed cartridge bearing

Saddle

Bontrager H1, 145mm width

Seatpost

Bontrager carbon, 27.2mm, 20mm offset, 330mm length (S, M), 400mm length (L, XL)

Seatpost Clamp

Knurled, quick release

Grips

Bontrager Satellite IsoZone Plus, lock-on, ergonomic

Front Hub

Formula DC-20, alloy, 6-bolt, 5x100mm QR

Rear Hub

Formula DC-22, alloy, 6-bolt, SRAM XD freehub, 135x5mm QR

Rims

Bontrager Paradigm, double-wall, tubeless ready, 32-hole, 21mm width, Presta valve

Spokes

Stainless steel, 14g

Exterior Features

Fender mounts, rack mounts, DuoTrap S compatible, internal cable routing, vibration-reducing grips

Weight

10.53 kg (M, estimated)
