Specification

Details

Model

FX 2 Midstep Gen 4

Vehicle Category

Hybrid Bike

Application

Fitness, commuting, casual riding

Starting Price (2025)

$899.99 USD

Color Options

Fjord Blue, White

Sizes

S, M, L

Specification

Details

Frame

Alpha Gold Aluminum, midstep geometry, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR

Fork

FX Alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR

Drivetrain Compatibility

Shimano CUES, 9-speed

Dropouts

135x5mm QR (F), 135x5mm QR (R)

Crank

ProWheel Pro alloy, 40T narrow-wide steel ring, 170mm length

Chain

Shimano LG500

Rear Derailleur

Shimano CUES U4000, 9-speed

Shifters

Shimano CUES U4000, 9-speed

Cassette

Shimano LINKGLIDE LG300, 11-46T, 9-speed

Specification

Details

Seating

Bontrager Sport Women's, steel rails, 155mm width

Cargo Capacity

Rack & fender mounts, kickstand mount

Wheels/Tyres

Bontrager H2 Comp, wire bead, 30 tpi, 700x35mm

Wheel Size

700c

Brakes

Tektro HD-R280 hydraulic disc, 160mm rotor

Brake Levers

Tektro HD-R280 hydraulic

Handlebar

Bontrager alloy, 31.8mm, 15mm rise, width: 660mm (S), 690mm (M), 720mm (L)

Stem

Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, length: 80mm (S-M), 90mm (L)

Headset

1-1/8" integrated, sealed cartridge bearing

Saddle

Bontrager Sport Women's, steel rails, 155mm width

Seatpost

Bontrager alloy, 27.2mm, 12mm offset, length: 330mm (S-M), 400mm (L)

Seatpost Clamp

Knurled, quick release

Grips

Trek Line Ergonomic Comp, lock-on

Front Hub

Bontrager alloy, sealed bearing, 6-bolt disc, 135x5mm QR

Rear Hub

Bontrager alloy, sealed bearing, 6-bolt disc, 135x5mm QR

Rims

Bontrager Connection, double-wall, 32-hole, 20mm width, Schrader valve

Spokes

Stainless steel, 14g

Pedals

Bontrager City pedals

Exterior Features

Rack & fender mounts, kickstand mount, internal cable routing

Weight

11.73 kg (M, estimated)
