Specification

Details

Model

Fuel LX 9 X0 AXS Gen 7

Vehicle Category

Mountain Bike

Application

Enduro riding, descending, trail riding

Starting Price (2025)

$6,199.99 USD

Color Options

Lithium Grey/Trek Black Splatter, Matte Juniper/Blue Sage Splatter, Deep Carmine

Sizes

S, M, L, XL

Specification

Details

Frame

Alpha NEXT Platinum Aluminum, 160mm travel, internal cable routing, adjustable geometry, 148x12mm thru axle

Fork

Fox Factory 38, Float EVOL air spring, GRIP2 damper, 170mm travel

Rear Shock

Fox DHX2, coil, 160mm travel

Drivetrain Compatibility

SRAM X0 Eagle AXS, 12-speed

Dropouts

15x110mm thru axle (F), 148x12mm thru axle (R)

Crank

SRAM X0 Eagle, 32T, 170mm (S, M), 175mm (L, XL)

Chain

SRAM GX Eagle, 12-speed

Rear Derailleur

SRAM X0 Eagle AXS, T-Type

Front Derailleur

N/A (1x drivetrain)

Shifters

SRAM AXS Pod Controller, 12-speed

Cassette

SRAM XS-1295, 10-52, T-Type, 12-speed

Specification

Details

Seating

Bontrager Arvada, hollow chromoly rails, 138mm width

Wheels/Tyres

Bontrager Line Comp 30, tubeless ready, 29x2.50"

Wheel Size

29" in

Brakes

SRAM Maven Silver, 4-piston hydraulic disc, 200mm rotors

Brake Levers

SRAM Maven Silver

Handlebar

Bontrager Line, alloy, 35mm, 27.5mm rise, 820mm width

Stem

Bontrager Line, 35mm, 0 degree, 40mm (S, M), 50mm (L, XL)

Headset

Knock Block Integrated, 1-1/8in top, 1.5in bottom, sealed cartridge bearing

Saddle

Bontrager Arvada, hollow chromoly rails, 138mm width

Seatpost

Bontrager Line Dropper, 100mm (S), 150mm (M, L), 170mm (XL)

Grips

Bontrager XR Trail Elite, nylon lock-on

Front Hub

Bontrager alloy, sealed bearing, 6-bolt, 15x110mm thru axle

Rear Hub

Bontrager alloy, sealed bearing, 6-bolt, SRAM XD freehub, 148x12mm thru axle

Rims

Bontrager Line Comp 30, tubeless ready, 30mm width

Spokes

14g stainless steel, black

Exterior Features

Adjustable geometry, internal cable routing, Knock Block, Mino Link adjustable suspension, downtube guard

Weight

15.2 kg / 33.51 lbs (size M)
