2025 Trek Fuel EXe 9.9 X0 AXS T-Type – Electric Full Suspension Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
Fuel EXe 9.9 X0 AXS T-Type |
|
Vehicle Category |
Electric Full Suspension Mountain Bike |
|
Application |
Trail riding, enduro, all-mountain with electric assist |
|
Starting Price (2025) |
$9,599.97 USD (sale), $13,199.99 USD (original) |
|
Color Options |
Dark Star, Black/Grey, Black/White |
|
Sizes |
S, M, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
OCLV Mountain Carbon, TQ HPR50 motor, Removable Integrated Battery (RIB), internal storage, adjustable geometry (Mino Link), tapered head tube, Knock Block, internal cable routing, ISCG 05 mount, 150mm travel, 148x12mm thru axle |
|
Fork |
RockShox Lyrik Ultimate, Charger 3 RC2 damper, DebonAir+ spring, AirWiz, 160mm travel, 44mm offset, 15x110mm thru axle |
|
Rear Shock |
RockShox Deluxe Ultimate RC2T, AirWiz, 205x60mm, 150mm travel |
|
Drivetrain Compatibility |
SRAM X0 Eagle AXS T-Type, 1x12-speed, wireless |
|
Dropouts |
148x12mm thru axle (R), 15x110mm thru axle (F) |
|
Crank |
SRAM X0 Eagle T-Type, 32T, 165mm length (S), 170mm length (M, L, XL) |
|
Chain |
SRAM X0 Eagle T-Type, Flattop, 12-speed |
|
Rear Derailleur |
SRAM X0 Eagle AXS T-Type, wireless |
|
Shifters |
SRAM AXS Pod Ultimate, wireless, 12-speed |
|
Cassette |
SRAM XS-1297 Eagle, 10-52T, T-Type, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Arvada, 138mm width |
|
Fuel Type |
Electric (Lithium-ion battery) |
|
Cargo Capacity |
Internal storage (Bontrager BITS bag included), downtube water bottle mounts |
|
Wheels/Tyres |
Bontrager Line Pro 30, OCLV Mountain Carbon, tubeless ready, 29x2.50", TyreWiz |
|
Wheel Size |
29" (F, R, except 27.5" R on S) |
|
Brakes |
SRAM Code Ultimate Stealth, 4-piston hydraulic disc, 200mm rotor (F), 180mm rotor (R) |
|
Brake Levers |
SRAM Code Ultimate Stealth, hydraulic |
|
Handlebar |
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5mm rise, 820mm width |
|
Stem |
Integrated with Bontrager RSL handlebar/stem, 35mm length |
|
Headset |
Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8" top, 1.5" bottom |
|
Saddle |
Bontrager Arvada, 138mm width |
|
Seatpost |
Bontrager Line Elite Dropper, 100mm travel (S), 150mm travel (M), 170mm travel (L, XL), 34.9mm, internal routing |
|
Seatpost Clamp |
Integrated, internal |
|
Grips |
Bontrager XR Trail Pro, alloy lock-on |
|
Front Hub |
Bontrager alloy, sealed bearing, 6-bolt, 15x110mm thru axle |
|
Rear Hub |
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, SRAM XD freehub, 148x12mm thru axle |
|
Rims |
Bontrager Line Pro 30, OCLV Mountain Carbon, tubeless ready, 28-hole, 29mm width, Presta valve |
|
Spokes |
14g stainless steel |
|
Exterior Features |
Adjustable geometry (Mino Link), internal storage (Bontrager BITS bag included), Knock Block, ISCG 05 mount, tubeless ready wheels with TyreWiz, downtube water bottle mounts |
|
Weight |
18.1 kg (M, estimated, including battery) |
|
Motor |
TQ HPR50, 50 Nm, 250W nominal power, 300W peak power |
|
Battery |
TQ 360Wh, Removable Integrated Battery (RIB), optional TQ HPR Range Extender 160Wh |
|
Display |
TQ LED display, Bluetooth connectivity |
|
Charger |
TQ 4A charger |
