2025 Trek Farley 5 – Fat Bike
Specifications
|
Specification |
Details |
|
Model |
Farley 5 |
|
Vehicle Category |
Fat Bike |
|
Application |
Snowy singletrack, winter bikepacking, off-season adventures |
|
Starting Price (2025) |
$1,999.97 USD (Sale from $2,199.99) |
|
Color Options |
Satin Blue Sage to Lithium Grey Fade, Baja Yellow |
|
Sizes |
S, M, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Alpha Platinum Aluminum, tapered head tube, internal derailleur and dropper post routing, rack and mudguard mounts, 197x12mm thru axle, BB86.5 PressFit, chainstay yoke |
|
Fork |
Farley carbon, tapered steerer, rack and cage mounts, 150x15mm thru axle |
|
Drivetrain Compatibility |
Shimano Deore M6100, 1x12-speed |
|
Dropouts |
197x12mm thru axle (R), 150x15mm thru axle (F) |
|
Crank |
Shimano Deore M6120, 30T, 170mm (S, M), 175mm (L, XL) |
|
Chain |
Shimano Deore M6100, 12-speed |
|
Rear Derailleur |
Shimano Deore M6100, long cage, 51T max cog |
|
Shifters |
Shimano Deore M6100, 12-speed |
|
Cassette |
Shimano Deore M6100, 10-51, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Arvada, steel rails, 138mm width |
|
Cargo Capacity |
Rack and mudguard mounts, multiple frame and fork cage mounts |
|
Wheels/Tyres |
Bontrager Gnarwhal Team Issue, tubeless ready, Inner Strength sidewalls, 27.5x4.5in |
|
Wheel Size |
27.5in |
|
Brakes |
SRAM Level hydraulic disc, 180mm front rotor, 160mm rear rotor |
|
Brake Levers |
SRAM Level |
|
Handlebar |
Bontrager alloy, 31.8mm, 15mm rise, 720mm width (S, M), 750mm width (L, XL) |
|
Stem |
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm (S), 70mm (M), 80mm (L, XL) |
|
Headset |
FSA IS-2, 1-1/8in top, 1.5in bottom, sealed cartridge bearing |
|
Saddle |
Bontrager Arvada, steel rails, 138mm width |
|
Seatpost |
Bontrager alloy, 31.6mm, 12mm offset, 330mm length |
|
Grips |
Bontrager XR Trail Comp, nylon lock-on |
|
Front Hub |
Bontrager alloy, sealed bearing, 6-bolt, 150x15mm thru axle |
|
Rear Hub |
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, 197x12mm thru axle |
|
Rims |
SUNRingle Mulefut 80 SL, 32-hole, 80mm width, Presta valve |
|
Spokes |
14g stainless steel, black |
|
Exterior Features |
Rack and mudguard mounts, multiple frame and fork cage mounts, chainstay yoke, tubeless ready wheels |
|
Weight |
14.35 kg / 31.64 lbs (size M) |
