Specification

Details

Model

Dual Sport 3 Gen 5

Vehicle Category

Hybrid Bike

Application

Commuting, fitness, light trail riding

Starting Price (2025)

$1,149.99 USD

Color Options

Pennyflake

Sizes

S, M, L, XL

Specification

Details

Frame

Alpha Gold Aluminum, internal cable routing, rack and fender mounts, 135x5mm QR

Fork

Dual Sport carbon, internal brake routing, fender mounts, 100x5mm QR

Drivetrain Compatibility

Shimano CUES, 1x10-speed

Dropouts

135x5mm QR (R), 100x5mm QR (F)

Crank

Prowheel, 42T, 170mm (S, M), 175mm (L, XL)

Chain

Shimano CUES LG500, 10-speed

Rear Derailleur

Shimano CUES U6000, long cage

Shifters

Shimano CUES U6000, 10-speed

Cassette

Shimano CUES LG400, 11-48T, 10-speed

Specification

Details

Seating

Bontrager Arvada, 138mm width

Cargo Capacity

Rack and fender mounts, frame bag compatibility

Wheels/Tyres

Bontrager Kovee, tubeless ready, 27.5x2.40"

Wheel Size

27.5" in

Brakes

Shimano hydraulic disc, MT201, 160mm rotor (F, R)

Brake Levers

Shimano MT201, hydraulic

Handlebar

Bontrager alloy, 31.8mm, 15mm rise, 720mm width (S, M), 750mm width (L, XL)

Stem

Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm (S), 70mm (M), 80mm (L), 90mm (XL)

Headset

FSA IS-2, 1-1/8" top, 1.5" bottom

Saddle

Bontrager Arvada, 138mm width

Seatpost

Bontrager alloy, 31.6mm, 12mm offset, 360mm length (S, M), 400mm length (L, XL)

Seatpost Clamp

Integrated, internal

Grips

Bontrager XR Endurance Comp, lock-on

Front Hub

Bontrager alloy, sealed bearing, 6-bolt, 100x5mm QR

Rear Hub

Bontrager alloy, sealed bearing, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR

Rims

Bontrager Kovee, double-wall, tubeless ready, 28-hole, 23mm width, Presta valve

Spokes

14g stainless steel

Pedals

Wellgo VPE-537, nylon platform

Exterior Features

Internal cable routing, rack and fender mounts, frame bag compatibility
