2025 Trek Checkpoint SL 6 AXS Gen 3 – Gravel Bike
Specifications
|
Specification |
Details |
|
Model |
Checkpoint SL 6 AXS Gen 3 |
|
Vehicle Category |
Gravel Bike |
|
Application |
Gravel adventures, far-out rides, bikepacking, light road |
|
Starting Price (2025) |
$3,999.97 USD (Sale from $4,399.99) |
|
Color Options |
Matte Hex Blue/Marianas Blue, Era White |
|
Sizes |
XS, S, M, ML, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, T47, rack and mudguard mounts, flat mount disc, 142x12mm thru axle |
|
Fork |
Checkpoint carbon, tapered carbon steerer, rack mounts, mudguard mounts, flat mount disc, 12x100mm thru axle |
|
Drivetrain Compatibility |
SRAM Rival AXS, 1x12-speed |
|
Dropouts |
142x12mm thru axle (R), 12x100mm thru axle (F) |
|
Crank |
SRAM Rival 1, 40T, DUB Wide, 165mm (XS), 170mm (S, M), 172.5mm (ML, L), 175mm (XL) |
|
Chain |
SRAM Rival, 12-speed |
|
Rear Derailleur |
SRAM Rival XPLR AXS, 44T max cog |
|
Shifters |
SRAM Rival AXS, 12-speed |
|
Cassette |
SRAM XG-1251, 10-44, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Bontrager Verse Short Comp, steel rails, 145mm width |
|
Cargo Capacity |
Rack and mudguard mounts, internal storage |
|
Wheels/Tyres |
Bontrager Girona Pro, tubeless ready, GR puncture protection, aramid bead, 60 tpi, 700x42mm |
|
Wheel Size |
700c |
|
Brakes |
SRAM Rival hydraulic disc, flat mount, 160mm rotors |
|
Brake Levers |
Integrated with shifters |
|
Handlebar |
Bontrager GR Elite IsoZone Gravel, alloy, 31.8mm, 40cm (XS, S), 42cm (M, ML), 44cm (L), 46cm (XL) |
|
Stem |
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm (XS), 80mm (S, M), 90mm (ML, L), 100mm (XL) |
|
Headset |
Integrated, cartridge bearing, sealed |
|
Saddle |
Bontrager Verse Short Comp, steel rails, 145mm width |
|
Seatpost |
Bontrager carbon, 27.2mm, 20mm offset, 330mm length |
|
Grips |
Bontrager Supertack Perf tape |
|
Front Hub |
Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle |
|
Rear Hub |
Bontrager alloy, sealed bearing, centerlock disc, SRAM XD-R freehub, 142x12mm thru axle |
|
Rims |
Bontrager Paradigm Comp 25, tubeless ready, 25mm width, Presta valve |
|
Spokes |
14g stainless steel, black |
|
Exterior Features |
IsoSpeed frame technology, internal storage, rack and mudguard mounts, tubeless ready wheels |
|
Weight |
9.05 kg / 19.95 lbs (size ML, with TLR sealant, no tubes) |
