Trakstar 531 – Agricultural Tractor by Trakstar
Specifications
|
Specification |
Details |
|
Tractor Model |
531 |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Type |
3 Cylinder, Diesel |
|
Engine Power |
31 HP |
|
Number of Cylinders |
Three |
|
Engine Capacity |
2235 CC |
|
Clutch |
Single Diaphragm |
|
Transmission Type |
Partial Constant Mesh |
|
Number of Gears |
8 Forward + 2 Reverse with High-Low Selector |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Oil Immersed Brakes |
|
Steering Type |
Mechanical Steering |
Components & Features
|
Specification |
Details |
|
Maximum Lifting Capacity |
1400 kg |
|
Hydraulics Type |
High-Tech, Fully Live – Position and Draft Control Lever |
|
Power Take Off |
Rear-Mounted, 6 Spline, 540 RPM |
|
Total Weight |
1800 ± 25 kg (Unballasted) |
|
Fuel Tank Capacity |
50 L |
|
Air Cleaner |
3 Stage Wet Type |
|
Additional Features |
350-Hour Service Interval, Positioning of Controls Designed for Comfort |
|
Wheel Base |
1880 mm |
|
Overall Length |
3410 mm |
|
Overall Width |
1735 mm |
|
Height |
2290 ± 25 mm |
