Specification

Details

Model

Orox R14 E-Adventure Bike

Vehicle Category

E-Adventure / Off-Road Touring

Application

Bikepacking, All-Terrain Touring, Adventure

Price (2025)

$9,999 USD

Wheel Size

29"

Specification

Details

Frame

Tern Orox, 6061-AL Patented Design

Fork

Atlas X Butted Chromoly

Motor

Bosch Performance Line CX (85 Nm, 340% Support)

Battery

Bosch 800 Wh (Dual up to 1,600 Wh)

Display

Bosch Kiox 300 Smart System

Drivetrain

Gates CDX Belt Drive with Rohloff 14-speed Hub (526% Range)

Brakes

Magura MT5 4-piston hydraulic disc

Rotors

203 mm front & rear

Tires

Schwalbe Johnny Watts 29 x 2.6"

Specification

Details

Weight

M: 34.9 kg (76.9 lb)

Speeds

1 x 14

Gear Inches

18" - 96" (1.45 - 7.64 m)

Suggested Rider Height

M: 155 - 185 cm ; L: 165 - 195 cm

Max Gross Vehicle Weight

On-road: 210 kg ; Off-road: 180 kg

Max Rider Weight

130 kg

Handlebar

Level Nine AL-7050 800 mm Riser

Stem

Level Nine Adjustable

Lighting

Ignis 700 Lumens Hi/Lo Beam front / LED Brake Light rear

Rack

Atlas X 100 kg Capacity

Smart Features

Bosch Connect Module (Alarm/Tracking)
