2025 Tern HSD S00 – E-Cargo Bike
Specifications
|
Specification |
Details |
|
Model |
HSD S00 E-Cargo Bike |
|
Vehicle Category |
E-Cargo / Compact Longtail |
|
Application |
Family Cargo, Urban Hauling |
|
Price (2025) |
$5,999 USD |
|
Wheel Size |
20" |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Tern HSD, 6061-AL Patented Design |
|
Fork |
Suntour Custom 70 mm Travel |
|
Motor |
Bosch Performance Line (75 Nm, 340% Support) |
|
Battery |
Bosch PowerPack 545 Wh |
|
Display |
Bosch Kiox 300 Smart System |
|
Drivetrain |
Gates CDX Belt Drive with Enviolo Heavy Duty Stepless Hub (380% Range) |
|
Brakes |
Magura MT4 hydraulic disc |
|
Rotors |
180 mm front / 160 mm rear |
|
Tires |
Schwalbe Big Ben |
Components & Features
|
Specification |
Details |
|
Weight |
28 kg (61.7 lb) |
|
Folding Size |
165 × 39.5 × 87 cm (65 × 15.6 × 34.3 in) |
|
Folding Time |
5 seconds |
|
Suggested Rider Height |
150 - 195 cm (4'11" - 6'5") |
|
Max Gross Vehicle Weight |
180 kg (397 lb) |
|
Max Rider Weight |
120 kg (265 lb) |
|
Speeds |
Stepless (∞) |
|
Gear Inches |
28" - 106" (2.23 - 8.47 m) |
|
Handlepost |
Tern Physis 3D Forged |
|
Stem |
Tern Andros Adjustable |
|
Seatpost |
Cane Creek Thudbuster G4 Suspension |
|
Rack |
Atlas H 80 kg Capacity |
|
Smart Features |
Bosch Connect Module (Alarm/Tracking) |
