Specification

Details

Chassis Platform

LP 410/33 BS VI

Wheelbase

2100 mm

Engine

TATA 275 MPFI03 WC

Engine Power

18.4 kW (25 HP) @ 4000 rpm

Engine Torque

49 Nm @ 2000-3000 rpm

Clutch Diameter

170 mm

Clutch Type

Single Plate Dry Friction

Gearbox

GBS 65/6.31, Synchromesh, 5 Forward + 1 Reverse

Brakes

Disc (Front) / Drum (Rear), Hydraulic

Suspension

Front: Semi-Elliptical Leaf Spring, Rear: Semi-Elliptical Leaf Spring with Hydraulic Double Acting Telescopic Shock Absorber

Steering

Manual, 380 mm

Battery

12 V, 35 Ah

Alternator

75 A

Tyres

155 R13 LT

Fuel Tank Capacity

60 L (10.8 kg CNG) + 5 L Petrol

Fuel Tank Material

Plastic

Max. GVW

1935 kg

Kerb Weight

1185 kg

Payload

750 kg

Seating Capacity

D+9

Length

3790 mm

Width

1500 mm

Height

1890 mm

TCD

8600 mm

Ground Clearance

150 mm

Gradeability

Petrol: 29.4%, CNG: 26%

AC / Non-AC Option

Optional HVAC

Fuel Type

CNG + Petrol

Application

Tourist Vans, School Vans

Specification

Details

Feature: Warranty

2 Years / 72,000 kms

Feature: Bus Body Warranty

3 Years / 3 Lakh kms

Feature: Fuel System

Advanced iCNG Technology; Plastic Fuel Tank with Fuel Monitoring System

Feature: Safety System

3-Point ELR Seat Belts; Fire Detection and Separation System; ABS with EBD; Child Lock; Immobilizer; Seat Belt Reminder

Feature: Seating Comfort

Most spacious van in the segment; Head Rest; Adjustable Headrest; Driver Seat Sliding; Armrest for Passengers; Book Pocket; Side Grab Handle; Molded Floor Carpet

Feature: Engine Efficiency

Fuel Efficient 694 cc Engine with Balanced Power & Torque; ECO Mode; Multi-Mode Fuel Economy Switch

Feature: Cooling System

E-Viscous Fan

Feature: Tyre Type

Low CRR Radial Tubeless & Tubetype Tyre (155 R13 LT)

Feature: Telematics

4G Telematic Solution with FOTA

Feature: Steering Wheel

Modular Steering Wheel with Cruise Control

Feature: Driver Comfort

Driver Suspended Seats; Digital Cluster; Multi Trip Meter; Digital Speedometer

Feature: Gear Shift Advisor

Torque Based Gear Shift Advisor

Feature: Visibility

Windshield Tinted Glass; Headlamp; Sunvisor (Driver Side)

Feature: Interior

Glove Box Lock; Dual Interior Color; Molded Floor Carpet; Fan; Music System

Feature: Stability Control

Electronic Stability Control with Hill Start Assist

Feature: Exterior

Body Color Bumper; Wheel Cover

Feature: Additional

Service Alert; USB Charger

Feature: Mileage

27.2 km/kg (CNG), 391.6 km range
