Tata LPT 4225 Cowl 2025 – Heavy-Duty Commercial Truck Chassis
Specifications
|
Specification |
Details |
|
Engine |
6700 cc, Cummins ISBe 6.7L, 6-cylinder, BS6 Phase 2, diesel, intercooled |
|
Power |
250 hp (186 kW) @ 2300 rpm |
|
Torque |
950 Nm @ 1000–1800 rpm |
|
Transmission |
9-speed manual, Tata G1150, synchromesh |
|
Brakes |
Full air S-cam brakes, dual-circuit, ABS |
|
Suspension |
Front: Parabolic leaf spring with shock absorbers; Rear: Semi-elliptical leaf spring with auxiliary springs |
|
Wheel Size |
22.5-inch |
|
Tyres |
295/95D20, radial, tubeless (10+1) |
|
Weight |
GVW: 42000 kg; Kerb Weight: ~9600 kg (chassis) |
|
Dimensions (LxWxH) |
9750 x 2550 x 1860 mm (chassis, 6800 mm wheelbase) |
|
Seat Height |
Not applicable |
|
Fuel Tank Capacity |
365 litres |
|
Mileage |
3–4 kmpl (claimed); ~2.5–3.5 kmpl (user-reported) |
|
Ground Clearance |
248 mm |
|
Price (Ex-Showroom, Delhi) |
₹37.20–42.50 lakh(Year-2025) |
Frame & Drivetrain
|
Specification |
Details |
|
Chassis |
Ladder-type heavy-duty frame with riveted/bolted cross members |
|
Engine Type |
Inline 6-cylinder, common-rail diesel, BS6, intercooled |
|
Clutch |
430 mm dia, single-plate dry friction |
|
Gearbox |
9-speed manual, Tata G1150, synchromesh |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Parabolic leaf spring with hydraulic double-acting shock absorbers |
|
Rear Suspension |
Semi-elliptical leaf spring with auxiliary springs |
|
Front Brake |
Full air S-cam drum brakes, dual-circuit, ABS |
|
Rear Brake |
Full air S-cam drum brakes, dual-circuit, ABS |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
Steel, 22.5-inch |
|
Tyres |
295/95D20, radial, tubeless (10+1) |
|
Wheel Size |
22.5-inch |
Components & Features
|
Specification |
Details |
|
Seat |
Not applicable (cowl chassis, custom cabin required) |
|
Handlebar |
Power steering (custom steering wheel with cabin) |
|
Instrument Cluster |
Digital, with gear shift advisor, fuel economy, AdBlue gauge (custom dashboard required) |
|
Features |
Fleet Edge telematics, electronic anti-fuel theft, customizable load body options (FSD, HSD, Container) |
|
Safety Features |
ABS, seat belts (with custom cabin), reverse parking sensors |
Available Colors
|
Specification |
Details |
|
Colors |
Arctic White, Arizona Blue |
