Specification

Details

Tractor Model

855 FE 4WD

Vehicle Category

Tractor

Fuel Type

Diesel

Application

Agricultural Tractor

Specification

Details

Engine Displacement

3478 cc

Engine Power

37.28-41.01 kW (50-55 HP)

Number of Cylinders

3 Cylinders

Rated RPM

2000 RPM

Air Cleaner

3 Stage Wet Air Cleaner

Clutch

12-inch Independent Standard Double Clutch (Independent PTO)

Transmission Type

Sliding Mesh/PCM

Number of Gears

8 Forward + 2 Reverse (Standard), 12 Forward + 3 Reverse (Optional)

Forward Speeds

2.60 to 30.90 km/h

Reverse Speeds

3.30 to 12.90 km/h

Shift Pattern

Centre Shift (Standard), Side Shift (Optional)

Front Axle Type

Drop Down

Front Axle Bracket

Casted

Specification

Details

Brakes

Oil Immersed Brakes

Steering Type

Balanced Power Steering

Specification

Details

Front Tyres

9.50 x 20 in (241.30 x 508.00 mm), 9.50 x 24 in (241.30 x 609.60 mm)

Rear Tyres

14.9 x 28 (378.46 x 711.20 mm), 16.9 x 28 (429.26 x 711.20 mm)

Specification

Details

Maximum Lifting Capacity

2000 kg

Power Take Off

540 RPM with Multispeed Forward & Reverse (CR-PTO)

Total Weight

2455 kg

Fuel Tank Capacity

62 litre

Additional Features

Swift Movement in Rough Terrain, Better Pulling Ability in All Soil Conditions, Less Slippage and Better Traction than 2WD, Enhanced Productivity, Scope to Attach Bigger Implements like MB Plough and Subsoiler

Hydraulic Controls

Position Control, Automatic Draft Control, Mix Control

Linkage

3-point Linkage Suitable for Category-I & II Type Implement Pins

DCV

Double Acting with Quick Release Coupling

Overall Length

3560 mm

Overall Width

1830 mm

Overall Height

2290 mm

Wheelbase

2165 mm

Wheel Track Front

1365 mm

Wheel Track Rear

1420 mm

Minimum Ground Clearance

350 mm
