Swaraj 742 XT – 2WD Tractor
Specifications
|
Specification |
Details |
|
Tractor Model |
Swaraj 742 XT |
|
Vehicle Category |
2WD Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tasks (Tilling, Hauling, Transporting) |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Type |
Water Cooled, Diesel |
|
Number of Cylinders |
3 |
|
Engine Rated RPM |
2000 |
|
Engine Power |
44-45 HP |
|
Engine Displacement |
3307 cc |
|
Bore and Stroke |
110 mm x 116 mm |
|
Service Interval |
400 h |
|
Transmission Type |
Sliding Mesh/Partial Constant Mesh |
|
Drive Type |
2WD |
|
Front Axle Type |
Adjustable/Fixed |
|
Number of Gears |
8 Forward + 2 Reverse |
|
Forward Speed Range |
3.00-30.92 km/h |
|
Reverse Speed Range |
3.76-12.91 km/h |
|
Power Range |
44-45 HP |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil Immersed Brakes |
|
Steering Type |
Mechanical/Power |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyre Size |
6.00 x 16 in |
|
Rear Tyre Size |
13.6 x 28 or 14.9 x 28 in |
Components & Features
|
Specification |
Details |
|
Hydraulic Control System |
ADDC with Single/Dual Remote Valve |
|
Three Point Linkage |
Category II |
|
Lifting Capacity |
1700 kg |
|
PTO Type |
Multi-Speed Forward and Reverse |
|
PTO Speeds |
540 r/min with 4 Multispeed Forward and 1 Reverse |
|
PTO Power |
38 HP |
|
Clutch Type |
Single/Dual Clutch (Independent PTO) |
|
Wheelbase |
2085 mm |
|
Weight |
2053 kg |
|
Overall Length |
3455 mm |
|
Overall Width |
1915 mm |
|
Overall Height |
2235 mm |
|
Ground Clearance |
440 mm |
|
Air Cleaner Type |
3-Stage Oil Bath |
|
Cooling System |
Water Cooled |
|
Fuel Tank Capacity |
56 litres |
|
Battery |
12V, 80 Ah |
|
Headlamps Type |
Glass |
|
Fender and Tail Lamps Type |
Regular |
|
Warranty |
6000 Hours or 6 Years |
|
Accessories |
Tow Hook, Canopy, Bumper |
|
Front Wheel Track |
1320 mm |
|
Rear Wheel Track |
1490 mm |
