Swaraj 724 XM Orchard NT – Agricultural Tractor by Swaraj
Specifications
|
Specification |
Details |
|
Tractor Model |
724 XM Orchard NT |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Model |
RV-2 XM+ 3A |
|
Engine Stroke |
4 Stroke |
|
Injection Type |
Direct Injection |
|
Cooling System |
Water Cooled with No Loss Tank |
|
Number of Cylinders |
2 Cylinders |
|
Bore and Stroke |
100 x 116 mm |
|
Engine Displacement |
1824 cc |
|
Engine Power |
18.64-22.37 kW (25-30 HP) |
|
Rated RPM |
1800 RPM |
|
Air Cleaner |
Dry Type, Dual Element with Dust Unloader |
|
Clutch |
Single Dry Friction Plate (Diaphragm Type) |
|
Transmission Type |
Sliding Mesh |
|
Number of Gears |
6 Forward + 2 Reverse |
|
Speeds |
Forward: 2.2 - 23.3 km/h, Reverse: 2.2 - 8.7 km/h |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Oil Immersed Brakes |
|
Steering Type |
Power Steering with Separate Steering Oil Tank |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
5.00 x 15in (127 mm x 381 mm) |
|
Rear Tyres |
9.5 x 24in (241.30 mm x 609.60 mm) |
Components & Features
|
Specification |
Details |
|
Maximum Lifting Capacity |
1000 kg |
|
Power Take Off |
540 RPM |
|
Total Weight |
1530 kg |
|
Additional Features |
Adjustable Check Chains, Live Hydraulics with ADDC, Position Control, Automatic Draft Control, Mix Control, 3-point Linkage (Category I & II), Electricals (12 Volt, 75 Ah Battery, Starter Motor, Alternator), Instruments (Engine RPM cum Hour Meter with Direction Indicators, Fuel Gauge, Ammeter, Water Temp Gauge, Oil Pressure Indicator), Suitable for PTO-driven Implements (Sprayer, Rotavator), Suitable for Inter-Cultivation and Orchard Operations |
|
Overall Length |
2930 mm |
|
Overall Width |
1110 mm |
|
Overall Height |
1440 mm |
|
Wheelbase |
1550 mm |
|
Wheel Track Front |
960 mm |
|
Wheel Track Rear |
840 mm |
|
Minimum Ground Clearance |
250 mm |
