Swaraj 717 – Agricultural Tractor by Swaraj
Specifications
|
Specification |
Details |
|
Tractor Model |
717 |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Stroke |
4 Stroke |
|
Injection Type |
Direct Injection |
|
Cooling System |
Water Cooled |
|
Number of Cylinders |
1 Cylinder |
|
Engine Displacement |
2300 cc |
|
Engine Power |
11.18 kW (15 HP) |
|
Rated RPM |
2300 RPM |
|
Air Cleaner |
3-stage Oil Bath Type |
|
Clutch |
Single, 199.8 mm diameter |
|
Transmission Type |
Sliding Mesh |
|
Number of Gears |
6 Forward + 3 Reverse |
|
Speeds |
Forward: 2.02 - 25.62 km/h, Reverse: 1.92 - 5.45 km/h |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Dry Disc Brakes |
|
Steering Type |
Mechanical Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
5.20 x 14 in |
|
Rear Tyres |
8 x 18 in |
Components & Features
|
Specification |
Details |
|
Maximum Lifting Capacity |
780 kg |
|
Power Take Off |
540 RPM @ 2053 engine RPM |
|
Total Weight |
850 kg |
|
Additional Features |
Side Shift Mechanism, Live Hydraulics with ADDC, Position Control, Automatic Draft Control, Mix Control, 3-point Linkage (Category I), Electricals (12 Volt, 50 Ah Battery, Starter Motor, Alternator), Instruments (Engine RPM cum Digital Meter, Fuel Gauge, Water Temp Gauge, Oil Pressure Indicator), Suitable for Rotavator, Cultivator, Spraying, Haulage, Sowing, Reaper, Threshing, Crops (Grapes, Groundnut, Cotton, Castor) |
|
Overall Width |
1210 mm |
|
Wheelbase |
1490 mm |
|
Wheel Track Front |
940 - 1040 mm |
|
Wheel Track Rear |
1000 - 1120 mm |
