Specification

Details

Model

Krampus

Vehicle Category

Hardtail Mountain Bike

Application

Singletrack, bikepacking, 29+ traction

Starting Price (2025)

$1,999.00 USD

Color Options

Prickly Pear

Specification

Details

Frame

Surly Krampus, 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, trumpet flared tubes, TIG welded, E.D. coated

Fork

Surly Krampus, 100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated, 483mm axle-to-crown, 47mm offset

Drivetrain Compatibility

1x12 speed, compatible with 1x (mtn: 28T, Boost: 30T), 2x (Boost: 24/36T)

Dropouts

Gnot-Boost spacing, 12x142mm or 12x148mm (Surly axle included), 10x135mm with Surly 10/12 Adapter Washers (not included)

Bottom Bracket

73mm threaded (1.37" x 24TPI), Shimano MT501, BSA

Crankset

Shimano MT511, 30T

Chain

KMC X12 Anti-Rust

Rear Derailleur

Shimano Deore M6100, SGS

Shifter

Shimano Deore M6100, 12-spd

Cassette

SunRace CSMZ800, 11-51T, 12-spd

Specification

Details

Seating

1 passenger (WTB Volt Medium saddle)

Fuel Type

Human-powered

Cargo Capacity

Supports racks, panniers, fenders, water bottle cages, three-pack mounts

Wheels/Tyres

Surly Dirt Wizard, 29 x 3.0", 60 tpi, Tubeless Ready

Wheel Size

29" in

Brakes

Tektro HD-M275, 2-piston, 51mm IS mount, 180mm front rotor, 160mm rear rotor, 6-bolt

Brake Levers

Tektro HD-M275

Handlebar

Salsa Rustler, 31.8mm, width 750mm (S), 800mm (M-XL)

Stem

Promax DA-296, 31.8mm, length 70mm (S-L), 80mm (XL)

Headset

Cane Creek, ZS44/28.6 upper, EC44/30 lower

Saddle

WTB Volt Medium

Seatpost

Promax, 30.9mm, 400mm

Seatpost Clamp

Surly Stainless, 33.1mm

Grips

Velo Black

Front Hub

Novatec 15x110mm, 32H

Rear Hub

Novatec 12x148mm, 32H

Rims

WTB ST i40 TCS 2.0, 40mm inner width

Spokes

14G

Interior Features

1 standard + 1 three-pack bottle mounts (S-M), 2 standard + 1 three-pack bottle mounts (L-XL), dropper post compatibility

Exterior Features

Rear fender mounts

Weight

32 lb 4 oz (Medium)
