Specification

Details

Tractor Model

STEYR TERRUS CVT 6315

Vehicle Category

Utility Tractor

Fuel Type

Diesel (Compatible with HVO)

Application

Rapid Transport, Heavy-Duty Field Work

Specification

Details

Engine

6-Cylinder, 6,728 cm³, Common Rail, Turbocharger with e-VGT, Intercooler, HI-eSCR2, Stage V, 24 Valves, Reversible Fan, Engine Exhaust Brake

Maximum Power

313 HP / 230 kW @ 1,800 RPM

Rated Power (ECE R120)

300 HP / 221 kW @ 2,100 RPM

Maximum Torque

1,282 Nm @ 1,400 RPM

Torque Increase

28%

Transmission Type

S-Control™ CVT, 0–50 km/h ECO or 0–40 km/h ECO, Double Clutch Technology, Active Hold Control, Kick-Down, S-Tronic Management

Fuel Tank Capacity

601 Litres (Diesel) / 96 Litres (AdBlue)

Service Intervals

Engine: 750 hours, Blow-By Filter: 1,500 hours

Frame

4-Pillar Cab, Semi-Active Suspension, 66 dB(A) Noise Level, Slimline Bonnet, One-Piece Windscreen, High-Visibility Roof

Steering

Hydraulic Load Sensing, Height/Tilt-Adjustable Steering Wheel, 55° Steering Angle, 7.7 m Turning Radius @ 1,930 mm Track Width, QuickTurn II

Specification

Details

Braking System

Wet Dual Brake Discs (4 Rear), Hydraulic, All-Wheel Brake with Opti-Stop, S-Brake Trailer Brake System, Electronic Parking Brake, Two-Line Compressed Air Braking

Specification

Details

Tyres

Front: 650/60R34, Rear: 710/75R42, Optional IF/VF Technology, Optional Central Tyre Inflation System (CTIS), Double Tyres Available

Specification

Details

PTO Type

Rear: 540/540E/1,000/1,000E RPM @ 1,871/1,598/1,853/1,583 RPM, Front: 1,000/1,000E @ 1,886/1,585 RPM, Electrohydraulic Engagement, PTO Management, Progressive Soft Start

PTO Shaft

1 3/8" 21-Splines, 1 3/8" 6-Splines, 1 3/4" 20-Splines

Hydraulic System

Closed Centre Load Sensing (CCLS), 165 l/min (Standard) or 220 l/min (Optional), 215 bar, Up to 5 Rear and 3 Mid-Mounted Electrohydraulic Valves, Power Beyond, Configurable Valves

Rear Lift

11,058 kg, Cat III/IVN, Electronic Hitch Regulation (EHR), Ride Control, High-Speed Tail Hook

Front Lift

6,016 kg, Remote Operating Switches, Seven-Pin Lighting, 40-A Plug Sockets

Driving Position

Dual-Motion Seat, Multicontroller III Armrest (Adjustable in 4 Directions), Infomat 1200 Touchscreen Monitor (52° Pivot), A-Pillar Display with Night Mode, Up to 24 LED Worklights (2,000–2,500 Lumens), Front/Rear Cameras, Wireless Camera, Deluxe/Active Luxury Cab with HVAC, Premium Speakers, Cooled Storage, Toolbox

Precision Farming

S-Guide (DGPS, RTK+ with 1.5 cm Accuracy, RTK FILL), S-Turn II, ISOBUS II/III, Easy-Tronic II, FieldOps™, Tractor Implement Management (TIM), Section Control

Additional Features

ECO-Drive™ Levers, Key Fob with Lock/Unlock and Anti-Theft, S-Tech Protect (3 Years/3,000 Hours Warranty), 24/7 Support

Dimensions

Length: 5,825 mm, Width: 2,536–2,993 mm, Height: 3,457 mm, Wheelbase: 2,995 mm

Track Width

Front: 1,858–2,258 mm, Rear: 1,840–2,052 mm (Flange Axle) or 1,840–2,374 mm (Adjustable Bar Axle)

Weight

11,530 kg (Shipping), 17,200 kg (Permissible Total)
