STEYR PLUS 4080 – 4WD Agricultural Tractor for Versatile Farming
Specifications
|
Specification |
Details |
|
Tractor Model |
STEYR PLUS 4080 (4WD) |
|
Vehicle Category |
Agricultural Tractor |
|
Fuel Type |
Diesel |
|
Application |
Mixed and Livestock Farms, Loader Work, Front/Rear Mounted Implements, Transport, Confined Spaces |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
FPT F5, Common rail, Turbocharged with intercooler, HI-eSCR2, 4 cylinders, 3600 cc, Stage V |
|
Rated Horsepower |
80 HP (59 kW) |
|
Maximum Horsepower |
80 HP (59 kW) |
|
Maximum Torque |
350 Nm at 1300 rpm |
|
Torque Increase |
43% |
|
Transmission Type |
S-Control 2, 24x24 2-speed Powershift with Powershuttle, 40 kph ECO |
|
Engine Speed at Max Power |
1900 rpm |
|
Rated Engine Speed |
2300 rpm |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Cab suspension |
|
Braking System |
S-Stop (Brake to clutch), Stop & Go functionality |
Wheels & Tyres
|
Specification |
Details |
|
Maximum Tyre Size |
Rear: 16.9 R38 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear: 540/540E/1000 at 1938/1535/1926 rpm, Mechanical front hitch with front PTO (optional) |
|
Hydraulic System |
Open Center, 82 l/min pump, Maximum pressure 210 bar, Up to 3 mechanical rear remote valves, 2 mechanical mid-mounted valves with joystick |
|
Rear Lift |
Mechanical Draft Control or Electronic Draft Control, Maximum lifting capacity 4700 kg, Lift-O-Matic system |
|
Front Lift |
Mechanical front hitch (optional) |
|
Weight |
Permissible total: 7000 kg |
|
Cab Features |
Hi-Visibility roof panel, Multicontroller armrest, Clear display for machine parameters |
|
Precision Farming |
S-Guide Autoguidance with 1.5 cm pass-to-pass accuracy, FieldOps telematics |
|
Telematics |
FieldOps: Remote monitoring, Data sharing, Crop/weather monitoring, Machine tracking |
