Specification

Details

Model

Turbo Levo 4 Expert

Vehicle Category

Electric Mountain Bike

Application

Full Power E-MTB Trail

Starting Price (2025)

$10,799.99 USD

Color Options

Satin Burnt Gold Metallic

Sizes

S2, S3, S4, S5, S6

Specification

Details

Frame

FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, SWAT storage, 150mm travel, side entry battery, fork travel up to 180mm

Fork

FOX 38 Performance Elite series, 29", GRIP X2 damper, 15x110mm axle, 44mm offset, 160mm travel

Rear Shock

FOX FLOAT X Performance Elite with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever with 3 setting Open mode tuning range, LSR adjustment, 210x55mm

Drivetrain Compatibility

SRAM GX Eagle T-Type AXS, 12-speed

Dropouts

15x110mm (F), 12x148mm UDH compatible (R)

Crank

SRAM GX Eagle Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm

Chain

SRAM GX Eagle Transmission Flattop Chain, 12-speed

Rear Derailleur

SRAM GX Eagle Transmission, Wired SRAM AXS battery

Shifters

SRAM AXS POD Controller

Cassette

SRAM GX Eagle Transmission Cassette, 12-speed, 10-52t

Specification

Details

Seating

Bridge Comp, Hollow Cr-mo rails

Fuel Type

Electric (Lithium-ion battery)

Cargo Capacity

SWAT internal downtube storage for trailside repair essentials

Wheels/Tyres

Front: Roval Traverse Alloy 29", Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"; Rear: Roval Traverse Alloy 27.5", Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"

Wheel Size

Mixed: 29" (F), 27.5" (R)

Brakes

SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm rotor (F), 200mm rotor (R)

Brake Levers

SRAM Maven Silver

Handlebar

Alloy handlebars, 35mm diameter, 8-degree backsweep, 6-degree upsweep, 780mm (S2), 800mm (S3-S5)

Stem

Alloy Trail Stem, 35mm bar bore

Saddle

Bridge Comp, Hollow Cr-mo rails

Seatpost

PNW Loam post with travel adjust, 125mm (S2), 170mm (S3), 200mm (S4-S6)

Seatpost Clamp

Alloy, 38.6mm

Grips

Deity Lockjaw grips

Front Hub

DT Swiss 370, 15x110mm, 28h

Rear Hub

DT Swiss 370 XD freehub body, 12x148mm, 32h

Rims

Roval Traverse Alloy, 29" (F), 27.5" (R), 30mm inner width, tubeless ready

Exterior Features

Adjustable geometry, SWAT internal downtube storage, mixed wheel setup, lifetime replacement suspension bearings, GENIE shock technology

Weight

24.41 kg / 53 lb, 13.0 oz (size S4)

Drive Unit

Specialized 3.1 motor, 666W power, 101Nm torque

Battery

Specialized Turbo X2, 840Wh integrated battery pack, up to 5.33 hour range

Charger

Specialized 4amp charger, 0-80% in under 1 hour

Display

MasterMind T3 Display System, 2.2" high-resolution color screen, customizable with Specialized app, Bluetooth integration

Certifications

Certified to UL 2849 (e-system) and UL 2271 (battery) by UL Solutions and/or SGS
