2025 Specialized Turbo Levo 3 Comp Carbon – Electric Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
Turbo Levo 3 Comp Carbon |
|
Vehicle Category |
Electric Mountain Bike |
|
Application |
Trail riding, all-mountain |
|
Starting Price (2025) |
$7,499.99 USD (was $8,999.99) |
|
Color Options |
Smoke / Black |
|
Sizes |
S1, S2, S3, S4, S5, S6 |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot |
|
Fork |
Fox 36 Rhythm, 29", 150mm (S1), 160mm (S2-S6), Grip damper |
|
Rear Shock |
FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm (S2-S6), FOX FLOAT DPS Performance (S1) |
|
Drivetrain Compatibility |
SRAM X01 Eagle, 12-speed |
|
Dropouts |
15x110mm thru-axle (F), 148mmx12mm thru-axle (R) |
|
Crank |
Praxis forged M30, custom offset, 160mm |
|
Chain |
SRAM GX Eagle, 12-speed |
|
Rear Derailleur |
SRAM X01 Eagle, 12-speed |
|
Shifters |
SRAM GX Eagle, trigger, 12-speed, single click |
|
Cassette |
SRAM XG-1275, 12-speed, 10-52T |
Components & Features
|
Specification |
Details |
|
Seating |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
|
Fuel Type |
Electric (Lithium-ion battery) |
|
Cargo Capacity |
SWAT CC steerer tube integrated tool with chain tool and link |
|
Wheels/Tyres |
Specialized, hookless alloy, 30mm inner width, tubeless ready, DT Swiss Industry spokes, 29x2.3" front (Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready), 27.5x2.3" rear (Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready), Standard Presta Valve tubes |
|
Wheel Size |
29" front, 27.5" rear |
|
Brakes |
SRAM Maven Bronze, 220mm rotor (F), 200mm rotor (R), metallic pads |
|
Brake Levers |
SRAM Maven Bronze, hydraulic |
|
Handlebar |
6061 mountain bars, 35mm diameter, 8-degree backsweep, 6-degree upsweep, 800mm width, 30mm rise (S1-S2), 40mm rise (S3-S6) |
|
Stem |
Alloy Trail Stem, 35mm bar bore |
|
Headset |
Integrated, sealed cartridge bearing |
|
Saddle |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
|
Seatpost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm, 100mm (S1), 125mm (S2), 150mm (S3), 170mm (S4-S5), 190mm (S6) |
|
Seatpost Clamp |
Alloy, 38.6mm |
|
Grips |
Specialized Trail Grips |
|
Front Hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
|
Rear Hub |
Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h |
|
Rims |
Specialized, hookless alloy, 30mm inner width, tubeless ready |
|
Spokes |
DT Swiss Industry |
|
Exterior Features |
Geo adjust head tube, geo adjust horst pivot, mixed wheel setup (29" front, 27.5" rear), SWAT CC steerer tube integrated tool |
|
Motor |
Specialized 2.2 Custom Rx Trail Tuned Motor, 90Nm torque, 565W power |
|
Battery |
Specialized M3-700, integrated battery, 700Wh |
|
Controller |
Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, with handlebar remote |
|
Charger |
Custom charger, 42V4A with Rosenberger plug, 100-240V |
