2025 Specialized S-Works Turbo Levo 4 – Electric Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
S-Works Turbo Levo 4 |
|
Vehicle Category |
Electric Mountain Bike |
|
Application |
Full Power E-MTB Trail |
|
Starting Price (2025) |
$15,399.99 USD |
|
Color Options |
Laurel Green Metallic |
|
Sizes |
S2, S3, S4, S5, S6 |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
FACT 11m Carbon with Carbon Link, 150mm travel, SWAT storage, side entry battery, adjustable head angle, BB height, chainstay length |
|
Fork |
FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, 160mm travel |
|
Rear Shock |
Fox Float X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment, 210x55mm |
|
Drivetrain Compatibility |
SRAM XX Eagle T-Type AXS, 12-speed |
|
Dropouts |
15x110mm QR (F), 12x148mm (R) |
|
Crank |
SRAM XX Carbon, 160mm, ISIS interface |
|
Chain |
SRAM XX, T-Type, 12-speed |
|
Rear Derailleur |
SRAM XX Eagle Transmission Derailleur |
|
Shifters |
SRAM AXS POD Ultimate with Discrete Clamp |
|
Cassette |
SRAM XS 1297 T-Type, 10-52, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
Specialized S-Works Power Mirror, Ti Rails, 143mm/155mm |
|
Fuel Type |
Electric (Lithium-ion battery) |
|
Cargo Capacity |
SWAT internal downtube storage for trailside repair essentials |
|
Wheels/Tyres |
Front: Roval Traverse HD Carbon 29", Butcher, GRID GRAVITY casing, GRIPTON® T9, TLR, 29x2.4"; Rear: Roval Traverse HD Carbon 27.5", Butcher, GRID GRAVITY casing, GRIPTON® T9, 27.5x2.4" |
|
Wheel Size |
Mixed: 29" (F), 27.5" (R) |
|
Brakes |
SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 220mm HS2 rotor (F), 200mm HS2 rotor (R) |
|
Brake Levers |
SRAM Maven Ultimate |
|
Handlebar |
Race Face Era Carbon, 35mm clamp, 8-degree back-sweep, 5-degree up-sweep, 800mm width, 40mm rise (S1/S2), 55mm rise (S3-S6) |
|
Stem |
Industry 9 Mountain, 35mm clamp, 40mm length |
|
Saddle |
Specialized S-Works Power Mirror, Ti Rails, 143mm/155mm |
|
Seatpost |
FOX Transfer NEO Factory, 34.9mm, 125mm (S2), 175mm (S3), 200mm (S4-S6) |
|
Seatpost Clamp |
Alloy, 38.6mm |
|
Grips |
Deity Lockjaw Grips |
|
Front Hub |
DT Swiss 240 DEG, 15x110mm, 32h |
|
Rear Hub |
DT Swiss 240 DEG, 12x148mm, 32h |
|
Rims |
Roval Traverse HD Carbon, 29" (F), 27.5" (R), hookless, 30mm inner width, tubeless ready |
|
Exterior Features |
Adjustable geometry, SWAT internal downtube storage, mixed wheel setup, lifetime replacement suspension bearings |
|
Weight |
23.68 kg / 52 lb, 3.3 oz (size S4) |
|
Drive Unit |
Specialized 3.1 S-Works motor, 720W power, 111Nm torque |
|
Battery |
Specialized Turbo X2, 840Wh integrated battery pack, up to 4.75 hour range |
|
Charger |
Specialized 12amp smart charger, 4 charge functions (Standard, Fast, Eco, 0-80% in under 1 hour) |
|
Display |
Mastermind TCU, 2.2" high-resolution screen, customizable with Specialized app, Bluetooth, Apple Find My integration |
|
Certifications |
Certified to UL 2849 (e-system) and UL 2271 (battery) by UL Solutions and/or SGS |
