Specification

Details

Model

S-Works Stumpjumper EVO T-Type

Vehicle Category

Trail Bike

Application

Trail riding, all-mountain, enduro

Starting Price (2025)

$6,999.99 USD (was $11,499.99)

Color Options

Satin Smoke / Cool Grey / Electric Green / Gloss Smoke Liquid Metal

Sizes

S1, S2, S3, S4, S5, S6

Specification

Details

Frame

FACT 11m carbon chassis and rear-end, asymmetrical design, 29/27.5 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel

Fork

FOX FLOAT 36 Factory, GRIP2 damper, 15x110mm, 44mm offset, 150mm (S1), 160mm (S2-S6)

Rear Shock

FOX FLOAT X2 Factory, Rx Trail Tune, 2-position open/firm lever, HSC, LSC, HSR, and LSR adjustment, 210x50mm (S1), 210x55mm (S2-S6)

Drivetrain Compatibility

SRAM XX Eagle Transmission, 12-speed

Dropouts

15x110mm (F), 12x148mm (R)

Crank

SRAM XX Eagle, Carbon, with Aluminum Guards, DUB, 32T, 165mm (S1), 170mm (S2-S5), 175mm (S6)

Chain

SRAM XX Eagle SL Transmission Flattop Chain, 12-speed

Rear Derailleur

SRAM XX Eagle Transmission Derailleur

Shifters

SRAM AXS POD Ultimate Controller

Cassette

SRAM XX Eagle SL Transmission Cassette, 12-speed, 10-52T

Specification

Details

Seating

Bridge, 155/143mm, Hollow Ti-rails

Cargo Capacity

SWAT™ Door integration (approx. 1L water sock, tool/food pocket)

Wheels/Tyres

Roval Traverse SL 29F/27.5R, hookless carbon, 30mm inner width, 2Bliss Ready, hand-built, 28h, DT Competition Race spokes, 29x2.3" front (Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready), 27.5x2.3" rear (Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready), Standard Presta tubes

Wheel Size

29" front, 27.5" rear

Brakes

SRAM Code Ultimate Stealth, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor (F and R)

Brake Levers

SRAM Code Ultimate Stealth, hydraulic

Handlebar

OneUp Carbon, riser bar, 5-degree upsweep, 8-degree backsweep, 35mm rise, 800mm, 35.0mm

Stem

OneUp Stem, 35mm bar bore

Headset

Integrated, sealed cartridge bearing

Saddle

Bridge, 155/143mm, Hollow Ti-rails

Seatpost

RockShox Reverb AXS, 30.9mm, 1X remote, 100mm (S1), 125mm (S2), 150mm (S3), 170mm (S4-S6)

Seatpost Clamp

Alloy, 38.6mm

Grips

Deity Lockjaw

Front Hub

Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing

Rear Hub

Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing

Rims

Roval Traverse SL 29F/27.5R, hookless carbon, 30mm inner width, 2Bliss Ready, hand-built, 28h

Spokes

DT Competition Race

Exterior Features

Asymmetrical design, 29/27.5 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, replaceable derailleur hanger

Weight

14.34 kg / 31 lb 9.8 oz (S4)
