2025 Specialized Diverge STR Expert – Gravel Bike

Images:

1

2

3

4

5

Specifications

Specification	Details
Model	Diverge STR Expert
Vehicle Category	Gravel Bike
Application	Gravel racing, adventure riding
Starting Price (2025)	$4,499.99 USD
Color Options	Clay / Powder Indigo / Metallic Sulfer
Sizes	49, 52, 54, 56, 58, 61

Frame & Drivetrain

Specification	Details
Frame	Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Fork	Future Shock 3.2 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount
Rear Shock	Future Shock Rear, 20mm travel
Drivetrain Compatibility	SRAM Rival eTap AXS / GX Eagle AXS, 12-speed
Dropouts	12x100mm thru-axle (F), 12x142mm thru-axle (R)
Crank	SRAM Rival 1 Wide
Chain	SRAM GX Eagle, 12-speed
Rear Derailleur	SRAM GX Eagle AXS, w/ battery cover
Shifters	SRAM Rival eTap AXS
Cassette	SRAM NX Eagle PG-1230, 12-speed, 11-50t

Components & Features

Specification	Details
Seating	Body Geometry Power Expert
Cargo Capacity	SWAT 4.0 internal downtube storage
Wheels/Tyres	Roval Terra C, 25mm inner width carbon rim, 32mm depth, DT 370 hub, 24h, DT Swiss Comp Race spokes, Tracer Pro 2BR, 700x42, Presta valve, 48mm
Wheel Size	700C front, 700C rear
Brakes	SRAM Rival eTAP AXS, hydraulic disc
Brake Levers	SRAM Rival eTap AXS
Handlebar	Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
Stem	Future Stem, Comp
Saddle	Body Geometry Power Expert
Seatpost	S-Works Carbon Seat Post, 20mm Offset
Seatpost Clamp	Specialized Alloy, 33.3mm
Grips	Supacaz Super Sticky Kush
Front Hub	DT 370 hub, 24h
Rear Hub	DT 370 Star Ratchet hub, 24h
Rims	Roval Terra C, 25mm inner width carbon rim, 32mm depth, 24h
Spokes	DT Swiss Comp Race spokes
Exterior Features	SWAT 4.0 internal downtube storage
Weight	9.93 kg (21 lb, 14.3 oz) for size 56
