2025 Specialized Crux Expert EX – Gravel Bike

Images:

1

2

3

4

5

Specifications

Specification	Details
Model	Crux Expert EX
Vehicle Category	Gravel Bike
Application	Adventure, racing
Starting Price (2025)	$4,999.99 USD
Color Options	Satin Cypress Metallic / Doppio / Dusky Pink / Champagne
Sizes	49, 52, 54, 56, 58, 61

Frame & Drivetrain

Specification	Details
Frame	Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
Fork	S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Drivetrain Compatibility	SRAM Rival eTap AXS, 12-speed
Dropouts	12x100mm thru-axle (F), 12x142mm thru-axle (R), UDH dropout
Crank	SRAM Rival 1x, 40T
Chain	SRAM Rival 12-speed
Rear Derailleur	SRAM Rival XPLR eTap AXS
Shifters	SRAM Rival eTap AXS
Cassette	SRAM XPLR, XG-1251, 12-speed, 10-44t

Components & Features

Specification	Details
Seating	Body Geometry Power Expert, titanium rails
Wheels/Tyres	Front: Roval Terra C, 25mm inner width carbon rim, 32mm depth, DT 370 hub, 24h, DT Swiss Comp Race spokes, Pathfinder Pro 2BR, Tan Sidewall, 700x38; Rear: Roval Terra C, 25mm inner width carbon rim, 32mm depth, DT 370 hub, 24h, DT Swiss Comp Race spokes, Pathfinder Pro 2BR, Tan Sidewall, 700x38
Brakes	SRAM Rival eTap AXS, hydraulic disc (F and R)
Brake Levers	SRAM Rival eTap AXS
Handlebar	Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare
Stem	Specialized Pro SL, alloy, 4-bolt, 6-degree rise
Saddle	Body Geometry Power Expert, titanium rails
Seatpost	Roval Terra Carbon Seat Post, 20mm Offset
Seatpost Clamp	Specialized Alloy, 30mm
Grips	Supacaz Super Sticky Kush
Front Hub	DT 370 hub, 24h
Rear Hub	DT 370 hub, 24h
Rims	Roval Terra C, 25mm inner width carbon rim, 32mm depth
Spokes	DT Swiss Comp Race
Exterior Features	Rider First Engineered™, lightweight carbon frame
Weight	8.07 kg / 17 lb, 12.7 oz (size 56)

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
