2025 Specialized Crux DSW Comp – Gravel Bike
Specifications
|
Specification |
Details |
|
Model |
Crux DSW Comp |
|
Vehicle Category |
Gravel Bike |
|
Application |
Adventure, racing |
|
Starting Price (2025) |
$2,799.99 USD |
|
Color Options |
Emerald Metallic |
|
Sizes |
49, 52, 54, 56, 58, 61 |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB, UDH dropout |
|
Fork |
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc |
|
Drivetrain Compatibility |
SRAM Apex, 12-speed |
|
Dropouts |
12x100mm thru-axle (F), 12x142mm thru-axle (R), UDH dropout |
|
Crank |
SRAM Apex DUB Wide, 40t |
|
Chain |
SRAM Apex D1 |
|
Rear Derailleur |
SRAM Apex XPLR, mechanical, 12-speed |
|
Shifters |
SRAM Apex |
|
Cassette |
SRAM Apex XPLR, 12-speed, 11-44t |
Components & Features
|
Specification |
Details |
|
Seating |
Body Geometry Power Sport, steel rails |
|
Wheels/Tyres |
Front: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples, Pathfinder 700x40, Tubeless Ready; Rear: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples, Pathfinder 700x40, Tubeless Ready |
|
Brakes |
SRAM Apex, Hydraulic Disc (F and R) |
|
Brake Levers |
SRAM Apex |
|
Handlebar |
Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare |
|
Stem |
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
|
Saddle |
Body Geometry Power Sport, steel rails |
|
Seatpost |
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware |
|
Seatpost Clamp |
Specialized Alloy, 30.8mm |
|
Grips |
Supacaz Super Sticky Kush |
|
Front Hub |
Specialized full sealed bearing thru axle hub, centerlock disc, 24h |
|
Rear Hub |
Specialized full sealed bearing thru axle hub, centerlock disc, 24h |
|
Rims |
DT Swiss G540 rim, 24mm internal width, tubeless ready |
|
Spokes |
DT Swiss Champion 14G stainless steel, DT Swiss brass nipples |
|
Exterior Features |
D'Aluisio Smartweld Technology, tapered head tube |
|
Weight |
9.44 kg / 20 lb, 13.0 oz (size 56) |
