Specification

Details

Model

Crux Comp

Vehicle Category

Gravel Bike

Application

Gravel racing, performance gravel riding

Starting Price (2025)

$3,799.99 USD

Color Options

Gloss Carbon / Purple Haze / Rebel Pink / Birch

Sizes

49, 52, 54, 56, 58, 61

Specification

Details

Frame

Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout

Fork

S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc

Drivetrain Compatibility

Shimano GRX RX820, 12-speed

Dropouts

12x100mm thru-axle (F), 12x142mm thru-axle (R), UDH dropout

Crank

Shimano GRX RX820

Chain

Shimano XT M8100, 12-speed w/ quick link

Rear Derailleur

Shimano GRX RX822-GS, 12-speed

Shifters

Shimano GRX RX820, 1x12-speed

Cassette

Shimano XT, 12-speed, 10-45t

Specification

Details

Seating

Body Geometry Power Sport, steel rails

Wheels/Tyres

DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples, Pathfinder Pro 2BR, Tan Sidewall, 700x38, 700x28/38mm, 48mm Presta valve

Wheel Size

700C front, 700C rear

Brakes

Shimano GRX RX820

Brake Levers

Shimano GRX RX820, 1x12-speed

Handlebar

Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare

Stem

3D-forged alloy, 31.8mm, 7-degree rise

Saddle

Body Geometry Power Sport, steel rails

Seatpost

Roval Terra Carbon Seat Post, 20mm Offset

Seatpost Clamp

Specialized Alloy, 30mm

Grips

Supacaz Super Sticky Kush

Front Hub

Specialized full sealed bearing thru axle hub, centerlock disc, 24h

Rear Hub

Specialized full sealed bearing thru axle hub, centerlock disc, 24h

Rims

DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h

Spokes

DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples

Weight

8.55 kg (18 lb, 13.6 oz) for size 56
