Sonalika 60 3 Cylinder – 60 HP 4WD Tractor for Heavy-Duty Farming
Specifications
|
Specification |
Details |
|
Tractor Model |
Sonalika 60 3 Cylinder |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Rotavator, Front End Loader, Cultivator, Disc Harrow, Trailer, Planter, Rotary Slasher |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
3100 FLT, 3 cylinders, Turbocharged, Dry type air cleaner, Cubic capacity: 2780 cc, Rated RPM: 2100, Max Torque: 230 Nm at 1300 RPM, Underhood/Upward exhaust, Cold start |
|
Gross Horsepower |
60 HP (44.7 kW) |
|
Transmission Type |
Swift Shift, Dual clutch, 8 Forward + 2 Reverse, 4WD, 4WD front axle |
|
Speed Range |
2.52 km/h (min) to 33.67 km/h (max) |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Oil-immersed brakes, Mechanical actuation, Independent parking brake |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Front: 9.5-24, Rear: 16.9x28, Optional: Front 9.5-20, Rear 16.9x28 |
Components & Features
|
Specification |
Details |
|
PTO Type |
540 |
|
Hydraulic System |
CAT-II 3-point linkage, Swinging drawbar stay bars, Lifting capacity: 2000 kg, 2DA auxiliary hydraulic circuit, Standard lift rods |
|
Fuel Tank Capacity |
62 L |
|
Width |
1790-1950 mm |
|
Wheelbase |
2350 mm |
|
Track Width |
Front: 1295-1650 mm, Rear: 1420-1880 mm |
|
Max Length |
3980 mm |
|
Max Height |
2650 mm (up to ROPS) |
|
Features |
In-house powerful 3-cylinder engine, Swift Shift 8F+2R transmission with jerk-free and noise-free gear shifting, Heavy duty lifting capacity (2000 kg), Parallelogram loader option for swift and easy loader operations, Integrated safety HVAC cabin (optional), Differential lock (standard), Battery: 12V, 88 Ah, Alternator: 12V, 36 Amp, Seven-pin trailer socket, Clutch safety switch, PTO safety switch, Neutral safety switch, Fuel indicator gauge, Front tow hook (inbuilt in front weight), Front and rear weights with standard ballast (base weight 72 kg + front weight 6x31 kg), Swinging drawbar, ROPS, Power steering |
