Solaris Urbino 24 Electric – Electric Bi-Articulated City Bus by Solaris Bus & Coach
Specifications
|
Specification |
Details |
|
Bus Model |
Urbino 24 Electric |
|
Vehicle Category |
Bi-Articulated Low-Floor Bus |
|
L x W x H |
24700 x 2550 x 3300 mm |
|
Wheelbase |
5870 mm |
|
GVW |
36000 kg |
|
Fuel Type |
Electric |
|
Application |
Electric Bi-Articulated City Bus |
|
Door Arrangement |
1-2-2-2-0, 1-2-2-2-2 |
|
Entrance Height |
320 mm |
|
Wheelchair Ramp |
Manually operated |
|
Number of Passenger Seats |
Max. 68 |
|
Max Speed |
70 kmph |
|
Range |
Up to 600 km |
Frame & Drivetrain
|
Specification |
Details |
|
Drive System |
2x electric portal axle ZF AVE130 2x125 kW |
|
Traction Batteries |
Lithium-ion, operation up to 24 h |
|
Battery Capacity |
Up to 1000 kWh |
|
Charging System |
Plug-in (standard), Pantograph (option) |
Suspension & Brakes
|
Specification |
Details |
|
Front Axle |
ZF independent suspension |
|
Fourth Axle |
ZF tag axle with active steering |
|
Rear Axle |
ZF steered rear axle |
|
Steering System |
RB Servocom |
|
Braking System |
EBS, ABS, ASR |
|
Suspension Levelling System |
ECAS air suspension with leveling and kneeling function |
Components & Features
|
Specification |
Details |
|
Central Lubrication |
Central lubrication point, solid lubricating grease |
|
Air-Conditioning (Driver’s Cabin) |
Electrical drive (option), Powered by passenger compartment unit (option) |
|
Air-Conditioning (Passenger Compartment) |
Electrical drive (option) |
|
Ventilation System |
Dual-function fans |
|
Roof Hatches |
Electric |
|
Passenger Compartment Heating System |
Water heating, electric water heater TJ40.3 (40 kW), convector-type heaters, 2-stage blowers |
|
Electrical Installation |
CAN-Bus system |
