Solaris Urbino 15 LE Electric Low Entry Bus
Specifications
|
Specification |
Details |
|
Model |
Urbino 15 LE Electric |
|
Overall Length |
14,890 mm |
|
Overall Width |
2,550 mm |
|
Overall Height |
3,465 mm |
|
Wheelbase |
7,000 mm (front axle to drive axle) |
|
Passenger Capacity |
Up to 65 seats, total up to 105 (depending on door arrangement and batteries) |
|
Certified Range |
Up to 250 km (depending on battery capacity and charging system) |
|
Fuel Type |
Electric |
|
Application |
Low Entry City and Intercity Bus |
Frame & Drivetrain
|
Specification |
Details |
|
Wheelbase |
7,000 mm (front axle to drive axle) |
|
Front Axle |
ZF independent suspension |
|
Drive Axle |
ZF portal axle |
|
Tag Axle |
ZF tag axle |
|
Electric Motor |
Asynchronous motor, 280 kW (standard) or 300 kW (option) |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
ECAS air suspension with leveling and kneeling function |
|
Brakes |
EBS (Electronic Braking System), ABS (Anti-Lock Braking System), ASR (Acceleration Slip Regulation) |
|
Steering |
RB Servocom |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
275/70 R22.5 or 295/80 R22.5 |
Components & Features
|
Feature |
Details |
|
Battery |
Lithium-ion, capacity over 470 kWh (6 packs, 2 roof-mounted, 4 in rear) |
|
Charging System |
Plug-in (above first axle left/right, front, or rear), optional pantograph (conventional roof-mounted or inverted), up to 260 kW (plug-in) or 540 kW (pantograph) |
|
Body Structure |
Stainless steel, removable side panels |
|
Door Arrangement |
1-2-0, 2-2-0, 1-2-1, or 2-2-1, entrance height 320 mm (275/70 R22.5 tyres) or 360 mm (295/80 R22.5 tyres) |
|
Wheelchair Ramp |
Manually operated at 2nd entrance |
|
Climate Control |
Driver’s cabin: optional air-conditioning (powered by passenger unit or electric drive); Passenger compartment: optional air-conditioning (electric drive or CO2 heat pump), dual-function fans |
|
Electrical Installation |
CAN-Bus system, central lubrication point with solid lubricating grease |
