Specification

Details

Bus Model

Trollino 18

Vehicle Category

Low-Floor Articulated Trolleybus

L x W x H

18000 x 2550 x 3400 mm

Wheelbase

5870 mm

GVW

28000 kg

Fuel Type

Electric

Application

Electric Articulated Trolleybus

Door Arrangement

1-2-2, 2-2-2, 1-2-2-2, 2-2-2-2

Entrance Height

320 mm

Wheelchair Ramp

Manually operated (standard), Electrically operated (option)

Number of Passenger Seats

Max. 45 + 8

Total Passenger Capacity

135 (40 seated)

Max Speed

70 kmph

Range

Up to 20 km off-wire

Specification

Details

Driveline System

MEDCOM ANT 250-600 (IGBT) asynchronous 250 kW 6-pole motor, Škoda BlueDrive (IGBT) asynchronous 250 kW 6-pole motor, MEDCOM ANT 250-600 (IGBT) asynchronous 240 kW 4-pole motor (option), Kiepe IMC 500 (IGBT) 2-axle drive: 2 asynchronous 160 kW 4-pole motors

Traction Batteries

Lithium-ion, operation up to 24 h

Battery Capacity

87 kWh (Solaris High Power batteries)

Pantographs

Manual (standard), Semiautomatic or automatic (option)

Specification

Details

Front Axle

ZF independent suspension (standard), ZF rigid axle (option)

Drive Axle

ZF portal axle

Central Axle

ZF neutral axle

Steering System

RB Servocom

Braking System

EBS, ABS, ASR

Suspension Levelling System

ECAS air suspension with leveling and kneeling function

Specification

Details

Central Lubrication

Central lubrication point, solid lubricating grease (standard); Central lubrication system with self-diagnostic, semi-fluid lubricating grease (option)

Air-Conditioning (Driver’s Cabin)

Electrical drive (option), Powered by passenger compartment unit (option)

Air-Conditioning (Passenger Compartment)

Electrical drive (option)

Ventilation System

Dual-function fans

Passenger Compartment Heating System

Water heating, electric water heater TJ40.3 (40 kW), convector-type heaters, 2-stage blowers

Electrical Installation

CAN-Bus system
