2025 Schwinn Roanoke 27.5in – Electric Bike
Specifications
|
Specification |
Details |
|
Model |
Roanoke 27.5in |
|
Vehicle Category |
Electric Bike |
|
Application |
gravel roads, and city pavement |
|
Starting Price (2025) |
$1,199.99 USD |
|
Color Options |
Slate |
|
Sizes |
One Size (5'5" - 5'10") |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Aluminum, 17.5", rigid, mountain |
|
Fork |
SR Suntour, 27.5", Hi-Ten steel, 100 mm bolt-on, 80 mm travel |
|
Crank |
Prowheel, aluminum, 170 mm, 42T |
|
Chain |
KMC |
|
Bottom Bracket |
Cartridge, square taper, 68 mm |
|
Shifters |
Microshift, 7-speed |
|
Rear Derailleur |
Microshift |
Components & Features
|
Specification |
Details |
|
Seating |
Schwinn, steel rails |
|
Fuel Type |
Electric |
|
Wheels/Tyres |
Aluminum, double wall, 27.5 in x 2.4 in, wire bead |
|
Wheel Size |
27.5" front, 27.5" rear |
|
Brakes |
JAK, cable actuated disc, aluminum, 180 mm front, 160 mm rear rotor |
|
Handlebar |
Aluminum, 700 mm width, 6° rise, 31.8 mm clamp |
|
Stem |
Aluminum, threadless, 80 mm, 7°, 31.8 mm clamp |
|
Headset |
Threadless, 1-1/8 in, ball bearing |
|
Saddle |
Schwinn, steel rails |
|
Seatpost |
Steel, 300 mm, 27.2 mm |
|
Grips |
Kraton |
|
Rear Hub |
Steel, 36H, 6-bolt |
|
Rims |
Aluminum, double wall, 36H, non tubeless |
|
Spokes |
14G/13G, stainless steel |
|
Pedals |
Steel/resin, reflector |
|
Weight |
69.89 lb |
E-Bike Features
|
Specification |
Details |
|
Motor |
500-watt hub drive motor |
|
Controller |
Multi-function LCD controller |
|
Range |
Up to 45 miles per charge |
|
Drive System |
Pedal assist and throttle |
|
Battery |
540 watt-hour internal downtube battery |
|
Max Speed |
20 MPH |
|
Recharge Time |
4 hours |
|
Certifications |
SGS certified to ANSI/CAN/UL2849 |
