SAME Frutteto Natural 70 – 4WD Utility Tractor
Specifications
|
Specification |
Details |
|
Tractor Model |
Frutteto Natural 70 |
|
Vehicle Category |
Utility Tractor (Specialized) |
|
Fuel Type |
Diesel, HVO Certified |
|
Application |
Orchards, Vineyards, Grounds Care, Material Handling |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
FARMotion 35, 3 Cylinders, 2,887 cm³, Common Rail @ 2,000 bar, Turbo Intercooler, Viscostatic Fan, Stage V, DOC+DPF, No AdBlue |
|
Rated Horsepower |
48 kW / 65 HP @ 2,200 RPM (ECE R120) |
|
Maximum Horsepower |
48.9 kW / 66 HP @ 2,000 RPM (ECE R120) |
|
Maximum Torque |
297 Nm @ 1,600 RPM |
|
Transmission Type |
Mechanical, 8+8 (4 Gears, 2 Ranges) or 10+10, 15+15 with Creeper, or 30+15 with Creeper and Mechanical Splitter, Synchronised Reverse Shuttle, Min Speed 0.28 km/h, Max Speed 40 km/h |
Suspension & Brakes
|
Specification |
Details |
|
Frame |
Standard Frame |
|
Suspension |
None (ROPS Platform) |
|
Braking System |
4-Wheel Braking with Multiplate Wet Disc Brakes, Mechanical Parking Brake, Optional Hydraulic Dual-Mode Trailer Brake |
|
Steering |
Independent Steering Pump (18 l/min), Max Steering Angle 55° |
Wheels & Tyres
|
Specification |
Details |
|
Standard Tyres |
13.6R28 (Rear, Reference Size) |
Components & Features
|
Specification |
Details |
|
PTO Type |
540/540ECO, Mechanical Engagement, Optional Groundspeed PTO |
|
Hydraulic System |
42 or 50 l/min Open Centre, 2 or 3 Rear Spool Valves (4–6 Ways), 18 l/min Dedicated Steering Pump |
|
Rear Lift |
Mechanical with SAC (Automatic Control Station), 2,700 kg (Compact) or 3,050 kg (Standard), Category I or II |
|
Driving Position |
2-Post Foldable ROPS, Digital Dashboard, Rear Working Lamp, Side Gear Levers, Colour-Coded Controls |
|
Fuel Tank Capacity |
65 L, No AdBlue |
|
Weight |
2,535 kg |
|
Wheelbase |
1,996 mm |
|
Height |
1,430 mm (ROPS Folded Down) |
|
Width |
1,450–1,640 mm |
