Specification

Details

Tractor Model

Delfino 50

Vehicle Category

Utility Tractor (Specialized)

Fuel Type

Diesel

Application

Vineyards, Orchards, Protected Crop Farming, Nurseries, Grounds Maintenance, Small Front Loaders

Specification

Details

Engine

Perkins, 4 Cylinders, 2,216 cm³, Common Rail, Turbo with Wastegate, Stage V, EGR+DOC+DPF

Maximum Horsepower

38 kW / 51 HP @ 2,600 RPM (ECE R120)

Maximum Torque

145 Nm @ 1,600 RPM

Transmission Type

Mechanical, 12+12 or 16+16 with Creeper, Synchronised, Min Speed 0.26 km/h, Max Speed 30 km/h at Economy Engine Speed

Specification

Details

Frame

Standard Frame

Suspension

Silent-Block Mounts (ROPS or Cab)

Braking System

4-Wheel Braking, Electrohydraulically Engaged Diff.Lock, Mechanically Engaged 4WD

Steering

Independent Steering Pump (15 l/min)

Specification

Details

Standard Tyres

320/70 R24 (Rear)

Specification

Details

PTO Type

540 (Standard), Optional 540ECO/1000, Optional Groundspeed PTO, Optional Mid-Mounted PTO 2000, Optional Front PTO 1000 (Electrohydraulic Engagement)

Hydraulic System

30 l/min Open Centre, 4–6 Rear Hydraulic Couplers, 2 Front Hydraulic Couplers, 2 Mid-Mounted Hydraulic Couplers, 15 l/min Dedicated Steering Pump

Rear Lift

Mechanical with SAC (Automatic Control Station), 1,320 kg, Category I or II, Position/Draft/Mixed/Float Control Modes

Front Lift

Optional, 730 kg

Driving Position

4-Pillar Cab or 2-Post Foldable ROPS, Silent-Block Mounted Platform, Adjustable Seat, Telescopic Steering Column, Digital Dashboard, Colour-Coded Controls, Optional Air Conditioning, Optional Active Carbon Air Filter, Openable Front Window, 2 Front + 2 Rear Working Lights, Radio Pre-Arrangement

Fuel Tank Capacity

40 L

Weight

1,600 kg (ROPS), 1,850 kg (Cab)

Wheelbase

1,800 mm

Height

1,306 mm (ROPS Folded), 2,283 mm (Cab)

Width

1,456 mm
