2025 Salsa Notch Deore 12 – EBike
Specifications
|
Specification |
Details |
|
Model |
Notch Deore 12 |
|
Vehicle Category |
EBike |
|
Application |
Enduro riding, trail riding |
|
Starting Price (2025) |
$3,599.99 USD (regular $5,999.00 USD) |
|
Color Options |
Silver |
|
Sizes |
Small, Medium, Large, X-Large |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Notch Aluminum, 6061-T6 aluminum, internal routing, 12x148mm, SRAM UDH derailleur hanger, Bosch BDU37 bottom bracket |
|
Fork |
RockShox Domain Gold RC, 170mm travel, 44mm offset |
|
Rear Shock |
Fox Float X Performance Series, 205 x 65mm |
|
Drivetrain Compatibility |
Shimano Deore M6100, 1x12-speed |
|
Dropouts |
15x110mm (F, Maxle Stealth, TP=M15x1.5, TL=9mm, 158mm overall), 12x148mm (R, Ø12 x 188mm, TP=1.0, TL=13) |
|
Crank |
FSA CK-762, RaceFace direct-mount chainring, 34t, MRP 1x SL TR2 chainguide for Bosch BDU37 |
|
Chain |
Shimano Deore M6100 HYPERGLIDE+ |
|
Rear Derailleur |
Shimano Deore M6100-SGS |
|
Shifters |
Shimano Deore M6100 |
|
Cassette |
Shimano Deore M6100-12, 10–51t, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
WTB Solano, Medium, Fusion Form, steel rail |
|
Fuel Type |
Electric (Bosch PowerTube 500 lithium-ion battery) |
|
Cargo Capacity |
1 full-size bottle mount, molded frame protection, Flip Chip, Split Pivot+ design |
|
Wheels/Tyres |
WTB ST i30 Tough TCS rim, 32h, Shimano TC500-15-B 15x110mm hub (F), Shimano TC500-MS-B 12x148mm hub (R), Teravail Kessel 29 x 2.6" Ultra Durable casing, WTB TCS Sealant included (F), Teravail Warwick 29 x 2.5" Ultra Durable casing, WTB TCS Sealant included (R), 2.0mm straight gauge black spokes |
|
Brakes |
Shimano Deore M6120, 4-piston, post mount, 200–220mm, Shimano Deore RT64 Center Lock rotors (220mm F/R) |
|
Brake Levers |
Shimano Deore M6100 |
|
Handlebar |
RaceFace Chester, 780mm wide, 20mm rise |
|
Stem |
Salsa Guide, 40mm |
|
Headset |
ACROS AZX-721, ZS56/28.6 (upper), ZS66/40 (lower), for 1.8" tapered steerer |
|
Saddle |
WTB Solano, Medium, Fusion Form, steel rail |
|
Seatpost |
TranzX YSP18, SM: 150mm travel, MD/LG/XL: 170mm travel, 30.9mm |
|
Seatpost Clamp |
35.0mm |
|
Grips |
WTB Wavelength |
|
Front Hub |
Shimano TC500-15-B, 32h, 15x110mm |
|
Rear Hub |
Shimano TC500-MS-B, 32h, 12x148mm |
|
Rims |
WTB ST i30 Tough, TCS, 32h |
|
Spokes |
2.0mm straight gauge, black |
|
Exterior Features |
1 full-size bottle mount, molded frame protection, Flip Chip, Split Pivot+ design |
|
Weight |
59 lb (~26.8 kg) for Medium, with tubes, no pedals |
|
Motor |
Bosch Performance Line CX, BDU37, Class 1, 85Nm torque, max assist 340% up to 600 watts, 20mph max assist speed |
|
Battery |
Bosch PowerTube 500 lithium-ion, 500Wh, 36V, 13.4Ah, removable for service |
|
Controller |
Bosch smart system, programmable via eBike Flow app, 4 assist levels (Eco, Tour, eMTB, Turbo) |
|
Charger |
Included, 100% charge: ~4.5 hours |
